5v-12v Ne555 Pulse Signal Square Wave Signal Generator Duty Cycle Adjust For Mcu

US $3200

Hong Kong, Hong Kong
May 24th

Open on mobile:
QR code

Welcome to my ebay store! You will find your favorite products. Pass by do not miss.thank you! Product Detail ( ---☆ ayanhu81 ebay shop welcome you to buy it ☆---) Note: This product is not a sophisticated circuit, is not suitable for use where high precision. Board Color : Green or Blue , send by random Applications: ( ---☆ ayanhu81 ebay shop welcome you to buy it ☆---) 1. As square wave signal generator generates a square wave signal for experimental development use. 2. used to generate drive a stepper motor drive square wave signal. 3. produce an adjustable pulse for MCU to use. 4. Have an adjustable pulse control-related circuits. Explanation: ( ---☆ ayanhu81 ebay shop welcome you to buy it ☆---) 1, Size: 35x33mm 2, the main chip: NE555; 3, the input voltage: 5V-15VDC. 5V supply, the output current can be around 15MA; when 12V power supply, output current is about 35MA; 4, the input current: ≥100MA; 5, the output amplitude: 4.2V V-PP to 11.4V V-PP (different depending on the input voltage, the output amplitude will be different);. 6, the maximum output current: ≥15MA (5V supply, V-PP is greater than 50%), ≥35MA (12V power supply, V-PP is greater than 50%); Advantages: ( ---☆ ayanhu81 ebay shop welcome you to buy it ☆---) 1, the output with LED indication, there is no straightforward output (low level LED lights, LED off at a high level, LED blink rate is relatively low); 2, the output frequency range of grades available, so that the output frequency is more continuously adjustable; Low-profile: 1Hz-50Hz IF file: 50Hz-1kHz High-frequency gear: 1KHz-10kHz High Frequency file: 10kHz-200kHz 3, the output frequency is adjustable; Cycle T = 0.7 (RA + 2RB) C VR1, VR2 is 0-10K adjustable; When the low-profile C = 0.001UF; When IF shift C = 0.1UF; High-frequency gear C = 1UF; When high-frequency gear C = 100UF, therefore frequency waveform buyers can own calculations. ( ---☆ ayanhu81 ebay shop welcome you to buy it ☆---) Package included: 1x NE555 Pulse Signal Square Wave Signal Generator Feedback > We maintain hightest buyer ratings > Positive Feedback will be much appreciated from you. > Any dissatisfaction, please contact us immediately! > Please do not leave neutral or negative feedback before we help you out. Payment > We accept PayPal only. > All major credit cards are accepted through secure payment processor PayPal. > Payment must be received within 7 days of auction closing. Shipping > We Ship to Worldwide, except Hong Kong, Nigeria..... > Items will be shipped within one business day on payment received. > Items are shipped from China using Airmail, delivery time depends on destination and other factors,reach most of the countries within 10 to 35 business days. Country Shipping Way Shipping Time Tracking Number United States China Post 7-12 Yes Russian China Post 15-35 Yes Other Country HK /Swiss Post Air Mail 15-45 No Brazil / Africa HK /Swiss Post Air Mail 35-65 No Returns > Defect: We will fully refund or send you a new replacement,please contact and return within 14 days. > Dissatisfaction: Please contact within 3 days, we will fully refund, after got your returned goods. > Missing parts/Q'ty: Please contact us immediately,for a new package arranged,or a partial refund issued. Contact us > If have any question, Please contact us by ebay message before leaving neutral, negative feedback or open any dispute, we will reply within 24hours, ensure that help you solve the problem, make you satisfied. > Our Working-time From 8:30 AM to 21:30 PM(GMT+08).
