6" Deluxe Super Rortary Index ( F36 )

US $2300

  • Norcross, Georgia, United States
  • Jun 3rd
Item No. 535-0016 Shipping weight: 113 lbs.  Features:  Commonly used in the shop applications, such as milling, drilling, jig boring etc Six masking plates for 2,3,4,6,8 and 12 divisions  Adjustable 10 second vernier 24 index plate is ground and hardened Specifications: Concentricity of chuck: 0.0005"  Through bore: 1.574"  Base parallelism : 0.0004"  Maximum individual spacing tolerance: 25 seconds Squareness : 0.0008” Chuck accuracy: 0.0005" TIR Chuck size: 6" Six masking plates, 6” 3 jaw chuck and chuck key are also included in the package
