6" W 18" L Supertec Stp-618m Surface Grinder, 3 Hp, Roller Ways On Tbl

US $8,490.00

Harrison, New Jersey, United States
Jan 30th

Open on mobile:
QR code

Thousands of Used Metalworking and Plastic Machines & New Machine Tools Photos, Full Descriptions and Prices - Fast & Easy About Us Shipping Payments & Checkout FAQs Our Inventory Home CNC Machines Manual Lathes, Mills, Drills, Saws Grinders, Hones, Finishing Fabricating Equipment Presses & Feeds Boring Mills Automatic Screw Machines EDMs Inspection Equipment Air Compressors Plastic Machinery Planers & Planer Mills Broaches & Keyseaters Shapers & Slotters Tooling & Accessories Welding Equipment Wire & Fastener Ovens, Furnaces & Environmental Misc Metalworking Gear Machinery Material Handling Misc Non-Metalworking 6" W 18" L Supertec STP-618M SURFACE GRINDER, 3 HP, Roller Ways on Tbl 6" Width 18" Length Supertec STP-618M SURFACE GRINDER, 3 HP, Roller Ways on Table Ref #: 137663 iammdna XNEWSG SUPERTEC MODEL STP-618M HIGH PRECISION HAND FEED SURFACE GRINDER FEATURES: - 3 HP V3 grade spindle motor for powerful output to achieve precision work standards and better grinding capability. - Cartridge spindle w/4 preloaded class 7 (p4) bearings and run-out of taper nose better than 0.000060" T.I.R. provides quiet, vibration free operation for better workpiece accuracy. - Optional 0.000050" micro down feed and micro cross feed is available (see below). - Vertical handwheel conveniently located at waist level. - The table traverses on linear ball bearings with hardened and ground guide ways to ensure smooth and easy movement of the table. - Double V cross ways are hand scraped and Turcite coated for greater flatness and high wear resistance. - All castings are tempered and stress relieved twice to assure stability of the machine structure and resist deflection under load. - Hardened & ground column ways with cast spindle slide is precision fitted for no "hang-up" gravity down-feed. - The Optional Mitsubishi PLC control uses a menu-driven LCD touch screen is easy to learn and easy to set. Simply fill in the blanks to set total grinding amount, rough increment, fine increment, sparkout passes, feeding direction, parking position, wheelhead retract distance, and press cycle start to complete automatic grinding cycle. (on the CII model only) - Grinding cycles for CII model: semi-automatic, surface, plunge, & crisscross. - Indexable table handwheel for ease of operation. - Work table flatness shall be within 0.00012". - The automatic lubrication system continuously floods saddle & column ways, bearings, and lead screws for better machine performance and less maintenance. Stringent quality control to Supertec specifications: - Work table flatness: 0.00012" - Parallelism of longitudinal movement: 0.0001"/18" - Parallelism of cross movement: 0.000080"/6" - Spindle parallel to work table: 0.0003"/12" - Run-out of wheel taper: 0.000060" SPECIFICATIONS: GENERAL CAPACITY Table size: .......................................................... 6" x 18" Max. grinding length:............................................ 19" Max. grinding width:............................................. 6" Distance from table surface to spindle center:........... 19" Standard chuck size: ............................................. 6" x 18" LONGITUDINAL MOVEMENT Manual traverse: ................................................... 20" Hydraulic traverse: (except 618M) ........................... 20" Automatic travel: (except 618M) ............................. 16-82 fpm CROSS MOVEMENT Manual traverse: .................................................... 7" Handwheel - Per revolution: .................................................... 0.2" - Per graduation: ................................................... 0.001" Max. length automatic feed ...................................... 6.5" (2A & CII only) VERTICAL DOWNFEED Rapid traverse: (CII) ............................................... 13 ipm Auto downfeed: (CII): ..................................... 0.0001"-0.002" Handwheel: - Per revolution: ..................................................... 0.05" - Per graduation: .................................................... 0.0001" MOTORS Spindle motor: ........................................................ 3 HP Hydraulic motor: (except 618M) ................................ 1 HP Crossfeed motor: (except 618M, 1A618) .................... 1/2 HP GRINDING WHEEL Wheel size: ...................................................... 8" x 1/2 "x 1 1/4 " Spindle speeds: ....................................................... 3450 rpm STANDARD ACCESSORIES: - Grinding wheel - Dust guard - Wheel flange - Diamond dresser - Wheel extractor - Balancing arbor - Leveling bolts and pads - Touch-up paints - Locating bolts - Tool box with tools - Splash guard (except 618M) - Machine lamp SPECIAL OPTIONS AND ACCESSORIES (call for pricing): MAGNETIC CHUCKS AND CONTROLs - Electromagnetic chuck (6" x 18") - Auto. Demagnetizer (must be ordered with above chuck) - Permanent magnetic chuck - O.S. Walker LBP (fine pole, 6"x18") - O.S. Walker ceramax permanent chuck (fine pole, 6"x18") - Automatic type control for O.S. Walker LBP chuck COOLANT SYSTEMS AND DUST COLLECTORS: - Coolant system (40L) - Coolant system w/paper filter (20L/min.) - Coolant system w/mag. sep. & paper filter (20L/min, 80L) - Combination coolant & dust collector (50L) - Dust collector only - Splash guards (must be ordered with any coolant system (618M only) - Universal wheel guard for side forming DRESSING ATTACHMENTS - Manual parallel dressing attachment SONY DIGITAL READOUT SYSTEMS - Two axis (Z & Y axis) digital readout - One axis (Vertical Travel Only) digital readout OTHER OPTIONS AND ACCESSORIES: - Balancing stand - Extra Grinding wheels - Spare wheel flanges - Micro down feed (0.000050") - Micro cross feed (0.000050") - Variable spindle speeds for wheelhead Machine Location: HARRISON, NJ Click Here For More Supertec Machines Click Here For More Grinders, Lappers & Hones - NEW SURFACE GRINDERS(s) Questions about this Machine? Call Kori at (800) 873-6224 ext 7555 Need a Freight rate? Call Alex, our recommended trucking and shipping broker at (973) 732-3274 effepbdc Finance This Equipment For Your Business - Click Here Buy With Confidence Machinery Values is one of the world's largest machinery dealers, in business since 1971. All used items bought from our eBay store are covered by a standard MDNA (Machinery Dealer's National Association) 30 day return privilege, which means you can return an item you are dissatisfied with for a full refund. Please click on our MDNA return privilege link for complete details on how this works. New machines are covered under their own warrantees. Details of each warranty can be found within the quotation for all new machines. Most items in our store are located in our warehouse in Harrison, New Jersey - about 9 miles from New York City. You may inspect any item prior to purchase, under power in most cases, simply by calling and arranging an inspection. There is no charge for this. We are a Certified Square Trade Seller - click on the Square Trade logo for details. Questions? Call us at: (973) 497-7500 Shipping Policy Will ship to Worldwide. TOP Payments & Checkout We accept PayPal, Visa & MasterCard and American Express, or contact us regarding other payment options. Please contact us soon after the auction ends (or Buy-It-Now ends listing) to tell us how you wish to pay and get any shipping quotes or pickup information you may require. Call Terry at 973-497-7612 regarding payments, and Alex at 973-497-7613 for shipping questions. TOP Frequently Asked Questions We offer a 30 day return privilege on all used machines sold from our stock (machines sold for clients and shipped from their plant locations are generally not covered - so ask if you’re in doubt). This return privilege is the industry standard MDNA return privilege which states the machine must be returned freight prepaid in the same condition it was shipped in (you can’t break it then return it) for a full refund of your purchase price, excluding shipping costs. TOP

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Supertec
Model	STP-618M
