600w Dc-dc Step-up Module Solar Laptop Power Supply 10-60v Liter 12-80v Power

US $240

Shenzhen, China
Jun 22nd

Open on mobile:
QR code

600W DC-DC step-up module solar laptop power supply 10-60V liter 12-80V power Description 600W power boost module, wide voltage input: 12V ~ 60V, 12V ~ 80V wide voltage adjustable output; output current can be adjusted; ultra-low input and output pressure. Detailed parameters: Input voltage: 12V-60V Input Current: Maximum input current 15A Output voltage: 12V-80V adjustable Output Current: 10A maximum output current Output Power: Effective power P = input voltage V * 10A Note: This needs to be stated, we refer to the nominal 600W maximum power module under certain conditions, at different input voltage, the maximum output power is limited by the maximum input current limit declined. For example, The input voltage is 12V: Maximum output power P = 12V * 10A = 120W The input voltage is 24V: Maximum output power P = 24V * 10A = 240W The input voltage is 60V: Maximum output power P = 60V * 10A = 600W Conversion efficiency: up to 95% (input voltage and current; output voltage and current impact of the conversion efficiency) Short circuit protection: Fuse Installation size: 73 * 51mm Details: 1 product materials chronological, using custom radiator, specification: Radiator bottom thickness 5mm, tooth height 21mm, length 85mm, width 63mm, boost the top plate is fixed radiator, rationalized design, integration design radiator and booster board , user directly, using long screws directly fixed to use. 2 toroid inductors using 27mm magnetic iron core, 1.4mm system inductance, high-quality high-frequency filter capacitor, enter a 470uF100V electrolytic capacitor, the output of two 470uF100V electrolytic capacitors, boost output and better power quality, power supply work instructions lamp with voltage regulation and current adjustment potentiometer so that the output is more convenient, you can always adjust the output voltage, the current size of the input and output terminals using 8500, through the strong current capability to ensure long and reliable operation. Applications: 1. DIY an output adjustable vehicle power supply, only need access to 12V input supply, the output voltage can be (14V-80V) freedom of continuous adjustment, but the output voltage can not be lower than the input voltage. 2 universal car laptop power supply. 12V power input connected to the output regulation voltage into the notebook needs to work. 3 boost charger, you can use 12V power supply is higher than 12V battery charging, for example, 24V battery and charging current can be adjusted. 4 is powered electronic equipment, as long as the voltage is regulated to the voltage and the current needs can not exceed the rated current is working properly. 5 pre-supply system, when doing a project, the input is 12V-18V, 24V power supply system board requires a lot about the power and ordinary DC-DC module power is too small, then the module will be your best choice, not debug directly on the machine to work, easy to achieve high efficiency power boost. Instructions for use: An input voltage range of options: the default shipping is 12-60V input, when you use the 12V battery or three strings, four strings of lithium, you can put the jumper on the map with a short jumper, select 9-16V input. Second, the output current adjustment methods: 1, CV potentiometer adjustment, according to your load requirements, the output voltage setting voltage value to your needs. 10 LED string voltage regulator such as 37V, 55V and so on four strings tune batteries. 2, CC potentiometer counterclockwise located about 30 laps, the output current is set to minimum, connect the LED, adjust CC potentiometer to the desired current. After charging for battery, the battery is discharged, and then to output, adjust to your desired current CC, (be sure to use for charging batteries completely discharged before being allowed to transfer, because the battery charge remaining in Vietnam more, the charge current is smaller.) Do not adjust the way with a short circuit current, the circuit structure of the booster module can not short-circuit the way tune. shipping list:1pcs 600W DC-DC step-up module solar laptop power supply 10-60V liter 12-80V power Payment We accept Paypal as the payment method. Shipping Free Shipping with Tracking Number!!! Every mail we post have a Tracking Number to check "where is my mail? How long i can get the goods!" The default shipping is by E-PACKET ( USPS )(7-12 working days) Item will be shipped within 2-3 working days after full payment is received. The delivery to most of the countries will take 1-2 weeks(7-12 working days) , if there's no problem when pass through the customs. We only ship to the approved address given in PayPal payment. Please make sure payment address in PayPal is correct. Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. Terms of Sale If you can't receive the product within 2 months (60 days), please contact with us,we promise to payback 100% of your money. We ensure our products work normally before post.If the products is broken before arrival to you,all you should do is taking a photo to show us our broken product.We promise to payback 100% of your money!!! About Us My Dear Friend! Welcome to my store!We are in the biggest market of Electronic Component!We will be the best friend with your Electronic diy!!!Thank you very much!!! Contact Us Welcome to travel to China ShenZhen!We can take you to the biggest market of Electronic Component and Play in ShenZhen! You can cantact us on ebay! We will Reply you in 24 hours!
