84X48 Nokia 5110 LCD Module with blue backlight adapter PCB 84*48 new, US $110 – Picture 0

84X48 Nokia 5110 LCD Module with blue backlight adapter PCB 84*48 new, US $110 – Picture 1

84X48 Nokia 5110 LCD Module with blue backlight adapter PCB 84*48 new, US $110 – Picture 2

84x48 Nokia 5110 Lcd Module With Blue Backlight Adapter Pcb 84*48 New

US $110

shenzhen, China
Jun 9th

Open on mobile:
QR code

Product Name: PCB LCD 84X48 84*48 Nokia 5110 Module with blue backlight adapter More Items In Our Store,Click Here! SKU: 1444 Parsts No. : Package: Brand: Quantity: 1 Note: 1. "LIGHT" linked with GND, the backlight to be lit. 2. Need you to compress the screen and PCB tighter, might got loose after the delivery. 3 Use a 3.3V controller, otherwise the display could be quite vague. To work as a display with an Arduino, this module needs a 100 ohm resistor on the Vcc pin to drop the voltage below 3.3v. With the resistor in place, it works perfectly and with good contrast. 1.Parameters 1>.Power supply voltage:2.7V-3.3V 2>.Data interface level:2.7-3.3V 3>.Backlight power supply voltage:highest 3.3V 4>.Module size:43.6mm x 43.1mm(width X height) 5>.Installation diameter:2mm 2.Connection 1>.RST--------- reset 2>.CE---------- chip selection 3>.DC---------- data/commands choice 4>.DIN--------- serial data line 5>.CLK--------- serial Clock Speed 6>.3.3V-------- VCC 7>.LIGHT------- backlight control terminal 8>.GND--------- power negative 3.Features: 1>. 84 X 84 dot matrix LCD,can show 4 lines of characters 2>. Use serial interface communicate with the master processor,the number of interface signal line reduced greatly, only 8 signal lines including power and GND.Support different types of MCU,such as the arduino,AVR,PIC,STM32,STC MSP430 and so on.Transfer rate up to 4Mbps,can full speed write display data without waiting time. 3>. Can use the conductive glue to connect the module with the printed board,without connecting cable.The metal hooks on the module can fix the module on the printed board,which is very easy to install and replace. 4>. LCD controller/driver chip has been bound to LCD chip,the volume of LCD is small 5>. Low power supply,the working current in normal situation is lower than 200?A,and has power-down mode Data download Below is a DIY cellphone photo shared by others on Arduino blog^_^ Note: If to connect 3.3V with LIGHT pin, the backlight will turn off. And this pin could be connected largest 3.3V, if higher than this voltage, the backlight could have been damaged. LIGHT is the negative pole of the backlight LED, therefore, only if you connect it to GND, the backlight will be lit. Dots Matrix LCD Display Modules TFT LCD Display Series Character Display LCD Modules IIC LCD Display Series MCU Chips 1. ATMEl AVR MCU 2 PIC MCU 3. STM32 MCU 4. C8051F 5. MSP430 MCU 6. 51 STC MCU Any problem, please contact us freely 1) We accept PayPal payment ONLY. On Mar-21-14 at 02:06:51 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
UPC	Does Not Apply
Model	PCB LCD
Country/Region of Manufacture	China
MPN	Does Not Apply
