1.8" Serial Tft Spi Lcd 128x160 Display Module St7735s 51/avr/stm32/arm 8/16 Bit

C $6.48

HK, Hong Kong
Jun 9th

Open on mobile:
QR code

Description Description - Size: 1.8 inch - Resolution:128 * 160 Instructions Program default IO connections: sbit LCD_CS = P0 ^ 0; Chip Select sbit LCD_RS = P0 ^ 2; data / command switch sbit LCD_SDA = P1 ^ 5; Data sbit LCD_SCK = P1 ^ 7; Clock sbit LCD_REST = P0 ^ 1; Reset ? TFT Power: Screen Power is 2.8-3.3V; remember not to use 5V (Modules with PCB's have inherited 3V regulator IC, you can enter 5V) ? backlight power supply (LED pin): 3.2V maximum backlight power (At 3.3V supply can be connected in series for 10 ohm current limiting resistor in series with 100 ohms or 5V Resistance). ? Data port level: theoretically can not let the data port level exceeds 3.3V, if you must IO connection with 5V microcontroller data bus, as tft internal voltage clamp, with Can be used, but is not always standard. You can do an experiment to test a sample batch Made product, in order to improve product stability, better use of low-voltage monolithic Machine or add a level converter IC. Package included: 1 x 1.8 inch 1.8" TFT LCD Display module ST7735S 128x160 51/AVR/STM32/ARM 8/16 bit W Detail Image Similar Items Payment 1.We accept PayPal only. 2.All major credit cards are accepted through secure payment processor PayPal. 3.Payment must be received within 7 business days of auction closing. 4.We ship to your eBay or Paypal address. Please make sure your eBay and Paypal address is correct before you pay. Shipping 1.We ship to your eBay or Paypal address. Please make sure your eBay and Paypal address is correct before you pay. 2.Items will be shipped within 1-3 business day when we received payment. 3.Delivery time depends on destination and other factors; 4.International buyers please note: a.Import duties, taxes and charges are not included in the item price or shipping charges. These charges are buyer’s responsibility. We will try our best to reduce the risk of the custom duties. b.Please check with your country's customs office to determine what these additional costs will be prior to buying. On 27-Aug-15 at 01:58:06 EDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded
MPN	Does Not Apply
