Ac 100a Power Meters Monitor Volt Amp Kwh Watt Digital Combo Meter Ac110v 230v

US $490

hong kong, Hong Kong
Jun 23rd

Open on mobile:
QR code

Specifications: 1) the working voltage: 80 ~ 260VAC 2) max power: 100A/22000W 3) working frequency: 45-65Hz 4) the measurement precision: class 1 About function 1) measure and monitor the electrical parameters (voltage, current, kWh, watt). 2) Overload alarm function (more than watt alarm threshold , backlight flashing). 3) power alarm threshold preset function (can set up their own power alarm threshold). 4) power(kWh) button reset function. 5) When power off, store the data, when on, continue the date. 6) large screen LCD liquid crystal screen full display function (voltage, current, kWh, watt). 7) backlight function. About Display display interface. By the large screen LCD display LCD monitor voltage and current, kWh, watt, electric parameters. 1) watt: the measurement range of 0~22kW less than 1kW: 0.0~999.9W less than 10kW: 1000~9999W; less than 22kW: 10.0~22.0kW. 2) kWh: the measurement range of 0~9999kWh less than 10kWh: 0~9999Wh ; more than 10kWh:10~9999kWh; 3) the test voltage range of 80~260V Display format 80~220V 4) current test range: 0~100A Display format 0.00~99.99A. About Button 1) backlight control Can turn on/off backlight by short press 2) power reset Step 1: long time press the button ( about 5 seconds), til display flicker, then release the button; Step 2: if short time press the button again, then power(kWh) reset zero and exit flicker; Step 3: if long press button for 5 seconds until it is no longer flicker, power(kWh) data is not cleared and exit. 3) set the alarm (watt) Step 1: long press the button, till the LCD screen display "SET CLr", release the button. Step 2: show the alarm(watt) value, short time press, value(number) increase don't press the button for 3 seconds, the setting switch to other bit. Step 3: long time press the button(about 5 seconds) ----> save the threshold watt value. threshold setting watt range: 0 ~ 22.0kW. Notices 1 suitable for indoor, not outdoor 2 not exceed the rated power. 3 wiring can not be wrong. Package Include ******************************************************************************************************************************** 1x AC 100A Power Meters Monitor Volt Amp kWh Watt Digital Combo Meter( with cover) 1x CT Our aim is to provide Top Level Customer Service, and our customer service specialists are always standing by to solve any of your problem. We greatly appreciate your 5-STAR POSITIVE feedback and please do NOT leave negative feedback without asking for help.
