Acterna Jdsu 2510 10gig Field Service Module 4 Fst-2000 Fst-2510 2510-15fc Oc192

US $2,995.00

Toledo, Ohio, United States
Jan 29th

Open on mobile:
QR code

Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: Acterna 2510-15FC 10-Gig Field Services Module (BC# 2740A) w/ Options VT100 SCR OC192 Remote Control BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! This Item Has A Current Calibration! Acterna 2510-15FC 10-Gig Field Services Module For Use With FST-2000 Test Pad (Not Included In Sale) 2510 Module Options: - VT100 - SCR - OC192 - Remote Control Working Condition: Excellent Condition: Refurbished Calibrated: Yes Warranty: 90 Day Exchange Warranty Acterna 2510 10-Gig Field Services Module Product Highlights Smallest, lightest OC-192/STM-64 test set on the market Ensures quality of service with multiple modes of operation to terminate and monitor circuits from various network access points Easy-to-use touch-screen graphical user interface (GUI) simplifies and expedites testing Modular TestPad 2000 architecture enables up-to-date support for established and emerging technologies in a single platform Engineered for the field with rugged construction and lightweight design Dual PCMCIA slots support easy installation of future upgrades and bring added testing functionality and versatility Application Highlights Turn up and maintain SONET/SDH rings and point-to-point links Provision 10-Gig signals carried across DWDM networks Verify end-to-end network performance by using bit error rate (BER) testing and a wide range of stress test patterns Assess network performance under abnormal conditions by inserting and simulating various errors and alarms Verify in-service network performance using Monitor and Through modes Acterna’s 2510 10-Gig Field Services Module is an all-in-one, integrated testing solution that helps translate rapid network deployment and service reliability into profitability. Designed specifically for field use, the rugged 2510 performs 10-Gig testing at OC-192/OC-192c and STM-64/STM-64c rates. It provides the flexibility, scalability, and upgradability to accommodate evolving testing needs while providing long-term protection for your test equipment investment. Function Highlights Test optical interfaces at OC-192/OC-192c and STM-64/STM-64c rates. Perform mapping analysis for both SONET and SDH tributaries: OC-192c and STS-48c/12c/3c/1 and STM-64c and STM/16c/4c/1/0. Transmit and receive 10-Gig signals at either 1310 nm or 1550 nm. Manipulate K1 and K2 byte values to verify proper protection switching. Configure and monitor tests using remote control commands. Features The 2510 meets the ever-changing needs of today’s transmission test workforce with powerful features that provide streamlined, reliable functionality across all applications. Because technicians can use this equipment with minimal training, testing objectives are addressed more quickly and costs of ownership are significantly reduced. Key features include: Application-Driven Icons—test application buttons are labeled with icons which clearly depict the way the test is performed on the circuit (e.g., circuit termination tests are labeled "TERM"). The icons and quick set-up buttons enable technicians to use the 2510 effectively, with very little training. Configurable Results (Quad Results™)—the 2510 streamlines the process of correlating results and quickly assesses network performance. Technicians can analyze selected results simultaneously in up to four windows. Physical and Laser Active LEDs—a bright array of physical LEDs on the front panel summarizes results and clearly identifies errors detected during a test. Laser Active LEDs indicate when the transmit laser is active and when laser pulses are received. Through Mode Capability—gain access to SONET/SDH circuits even when no test access is provided. Through mode capability at 10-Gig for advanced SONET/SDH testing monitors circuits by channeling network traffic through the 2510 module. Signal Power and Frequency Verification— ensure optical power and frequency measurements received are within acceptable error limits. VT100 Terminal Emulation—perform VT100 terminal emulation to connect to network elements in order to execute configurations and monitor available statistics. Applications The 2510’s easy-to-use interface streamlines the process of analyzing SONET/SDH network performance. It supports numerous mappings, which enable testing and verification of individual payloads inside a 10-Gig signal. Technicians can manipulate K1 and K2 bytes to test automatic protection switching, and they can use the 2510’s support for user-configurable path trace messages to name and identify trace messages and payloads. The built-in attenuator connects to either the transmitted or received signal, so tests can be performed without saturating the network’s or the 2510’s optical receiver. Commission SONET/SDH Rings and Point-to-Point Links Manufacturers installing 10-Gig SONET/SDH rings must ensure proper network operation before the customer will accept the network elements. The 2510 tests the ADM transmitted and received signals and its response to errors, alarms, and protection switching. In addition, the 2510 tests lower rate tributaries running within the OC-192/STM-64 down to the STS-0/VC-3 level, verifying the proper mapping of these tributaries within the ring. Qualify 10-Gig Signals over DWDM Networks When DWDM networks are deployed, wavelengths carrying a 10-Gig SONET/SDH link must be qualified for carrying traffic. Turn up channels by using the 2510 to terminate test patterns over each wavelength via a BER test. Verify End-to-End Network Performance In the future, OC-768/STM-256 networks will be deployed to carry traffic along capacity-starved routes. The 2510 provisions the OC-192c/STM-64c tributaries within to ensure the connectivity and quality of the service. Optical power measurements, BER testing, pointer justification measurements, and path trace identifiers ensure proper ADM mapping and tributary line card operation for error-free transmission. Perform Network Analysis under Simulated Abnormal Conditions Generate and analyze a comprehensive range of errors and alarms to simulate abnormal conditions. SONET errors include Bit, Section BIP, Line BIP, Path BIP, Line FEBE, Path FEBE, and Frame word. SONET alarms include Line AIS, Line RDI, Path AIS, Path LOP, and Path RDI. SDH errors include Bit, B1, B2, B3, MS RDI, HP RDI, and FAS word. SDH alarms include MS AIS, MS RDI, AU-4 AIS, AU-4 RDI, and AU-4 LOP. Conduct In-Service Monitoring of OC-192/STM-64 Signals The 2510’s Monitor/Through mode allows visibility into the SONET/SDH signal while it carries revenuegenerating customer traffic. Troubleshoot and sectionalize network problems by analyzing the overhead and payload—without incurring downtime. Technical Specifications PHYSICAL CHARACTERISTICS Overall Dimensions ..................7.5 x 11.5 x 2.25 inches (19 x 29.2 x 5.7 cm) Overall Weight ....................9 lbs. (4.1 kg), with battery ENVIRONMENT Temperature Range Operating ................................................32° F to 104° F 0° C to 40° C Storage......................................................-4° F to 158° F -20° C to 70° C Shock and vibration..............................Meets IEEE-743 POWER REQUIREMENTS AC Adapter ......................................19 VDC, 2.95 amps 90 - 240 VAC, 45 - 65 Hz DISPLAY ................................6-inch diagonal graphic LCD color OPTICAL SPECIFICATIONS FOR OC-192/STM-64 Optical Connectors ...................................1 10-Gig Receive – FC, SC, or ST 1 10-Gig Transmit – FC, SC, or ST 1 Attenuator In – FC, SC, or ST 1 Attenuator Out – FC, SC, or ST Transmitter (Single mode fiber compatible) Wavelength .......................................Standard: 1550 nm Optional: 1310 nm Clock Frequency Accuracy ...............................± 3 ppm High Power TX Output ...........+ 3.0 dBm to –2.0 dBM Attenuation.......................................10 dBm attenuator Receiver (Single mode fiber compatible) Wavelength................................................1280-1580nm Rx Clock Frequency ..........................................± 3 ppm Receive Level Sensitivity ..........–1.0 dBm to –15.0 dBm SONET SPECIFICATIONS Rates ....................................................................OC-192 Line code..............................Non-return to zero (NRZ) Structure ..........................................STS-192c, STS-48c, STS-12c, STS-3c, STS-1 Synchronization...............................Internal, recovered, 2M reference, T1 reference Error injection........Section, Line, and Path BIP errors, Frame word errors, Line and Path FEBE, bit errors in a test pattern Alarm generation ...................Signal loss, loss of frame, Line-AIS, Line-RDI, Path-LOP, Path-AIS, Path-RDI Triggering...............................Single error or error rate: 1 X 10-4 to 1 X 10-9 Trace identifier ..........................J1 has a programmable 64-byte ASCII sequence Test patterns ...............223-1, 223-1 (inverted), 231-1, 231-1 (inverted), auto Pointer control.................± 1 increment or decrement, NDF, pointer value SOH ........................Interpretation of APS information in the K1 and K2 bytes Results Display specifications Event Log ...........................Displays all alarm and error events with a time stamp 50 ms resolution of error events and parameters 500-line memory capacity Numerical Display......Display of count (absolute) and rate (relative) values of error types Display Update Rate..........................................1 second Results Printout ...............................Manually triggered or timed print Serial ............................................................V.24/RS-232 Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. UPS Ground United States USD 0.00 USPS Express Mail International (EMS) Worldwide USD 0.00 We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Put your auctions on autopilot with Kyozou eBay Auction Software

Condition:	Seller refurbished: An item that has been restored to working order by the eBay seller or a third party not approved by the manufacturer. This means the item has been inspected, cleaned, and repaired to full working order and is in excellent condition. This item may or may not be in original packaging. See the seller’s listing for full details. ...	Brand	JDSU
Model	2510-15FC
