Actuonix P16 Linear Actuator, 100mm, 64:1, 12v W/ Potentiometer Feedback

US $103.50

Swanton, Vermont, United States
Aug 30th

Open on mobile:
QR code

Description Actuonix P16 Linear Actuator 12V w/ Potentiometer Feedback Peak Power Point 80N @9mm/s Gear ratio: 64:1 Max Speed (no load) 18mm/s Stall Current 1000mA @ 12V Stroke: 100mm The P16 Linear Actuator, 100mm, 64:1, 12V w/ Potentiometer Feedback offer no built-in controller, but do provide an analog position feedback signal that can be input to an external controller. It can be used with Linear Actuator Control Board (LAC) to give it the ability to be controlled with USB, 0-5v, 4-20mA, RC Servo or PWM. On board adjustment of speed, sensitivity and stroke limits are available via the LAC. Specifications Gearing Option Peak Power Point: 80N @9tim/s Peak Efficiency Point: 40N @14mm/s Max Speed (no load): 18mm/s Max Force Lifted: 90N Back Drive Force: 200N Stroke Option Mass: 110g Repeatability (-P & LAC): 0.4mm Max Side Load: 15N Closed Length hole to hole: 147mm Feedback Potentiometer: 11kΩ±50% Feedback Linearity: Less than 2.00% Input Voltage: 0-15 VDC. Rated at 12VDC. Stall Current: 1000mA @ 12V Operating Temperature: -10°C to +50°C Audible Noise: 62 dB @ 45cm Ingress Protection: IP-54 Mechanical Backlash: 0.3mm Limit Switches (-S): Max. Current Leakage: 8uA Maximum Static Force: 500N Maximum Duty Cycle: 20%

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Actuonix
Type	Actuonix
MPN	P16-100-64-12-P
UPC	Does not apply
