Ad9833 Dds Signal Generator Module Sine / Square / Triangle Wave 0 Mhz~12.5 Mhz

US $40.88

Wuhan, China
Mar 14th

Open on mobile:
QR code

AD9833 DDS Signal Generator Module Sine / Square / Triangle Wave 0 MHz~12.5 MHz Specification: 1.AD9833 ADI is the production of a low power consumption and programmable waveform generator, can produce sine wave, triangle wave, square wave output. 2.Waveform generator widely applied in all kinds of measurement, motivation and time domain response field. 3.AD9833 without external components, output frequency and phase can be through software programming, easy to adjust. 4.Frequency register is 28, the main frequency clock for 25 MHz, precision is 0.1 Hz; 5.Main frequency clock for 1 MHz, precision can reach 0.004 Hz. Can through the three serial interface will AD9833 data writing, the three serial frequency can reach the highest working 40 MHz, easy and DSP and all kinds of mainstream micro controller compatible. 6.AD9833 working voltage range of 2.3 V-5.5 V. AD9833 also has dormancy function, can not be used part of dormancy, reduce the part of the current loss. For example, if use AD9833 output as a clock source, can let the DAC dormancy, to minimize power consumption. 7.This circuit using 10 pin type MSOP surface patch encapsulation, is small in size. Feature: AD9833 performance index: 1.Working voltage of 3 V, power consumption is only 20 mW; 2.Output frequency range is 0 MHz ~ 12.5 MHz; 3.Frequency register for 28 (25 MHz reference clock in, the precision of 0.1 Hz); 4.Can choose sine wave, triangle wave, square wave output; 5.No external components, 3 line SPI interface; 6.The output waveform: sine wave, square wave, triangle wave. 7.Output impedance: 50 ?-10%; 8.Output frequency range: (the valid range 5 M) Sine wave: 1 Hz-3 MHz (higher than 3 MHz waveform jitter larger); The triangle wave: 1 Hz-2 MHz (higher than 2 MHz waveform jitter larger); Party wave: 1 Hz-2 MHz (higher than 2 MHz waveform jitter larger); 9.Resolution: 1 Hz; Package: 1* DDS signal source; 1* 9 V / 1 A switching power supply 1* The signal source special BNC-alligator clip article line PayPal Preferred Shipping & Delivery We provide free shipping to international via China Post Airmail or Hong Kong Post Airmail, and every parcel will be registered with tracking number. We can also ship by UPS/EMS/DHL/FedEx for alternative shipping method for corresponding fees. International customers may experience delays by customs or national post providers. Review your duty-free limits. Please let us know before payment if you need split shipment. Time of Delivery The time to ship to international via China Post Airmail or Hong Kong Post Airmail quite depends on different destination of the world, it is also subject to change due to the local weather conditions, postal policy and custom checking. Based on the postal Air mail rules and our experience, kindly please be noted that To United States / United Kingdom / Australia, it takes around 10-15 business days; To Canada, it takes around 12-18 business days; To Brazil / South America, it takes around 25-35 business days. To Italy / France / Spain / Germany/ Eastern Europe, it takes around 15-20 business days. Returns & Replacements & Repair We accept returns & replacements within 14 days from the day the customer receive the products, please make first contact within 14 days from receiving the order. Products should be returned in original condition. As a benefit to our customers, we also provide repair within 3 months from the day when this item is shipped out, after repair is done, we will send you the item, but the customer should pay both shipping ways. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
