Adc 30msps 10bit A/d Converter Parallel Out Ths1031 X2-:

US $47

Valley Stream, New York, United States
Jan 29th

Open on mobile:
QR code

THS1031IDW 30 MSPS, 10-BIT CMOS ADC Parallel data output for easy interface and experimenting Case: SOIC-28 Lot Size: 2 units See other listings and lot sizes for this item See other ADCs The THS1031 is a CMOS, low-power, 10-bit, 30 MSPS analog-to-digital converter (ADC) that can operate with a supply range from 3 V to 5.5 V. The THS1031 has been designed to give circuit developers flexibility. The analog input to the THS1031 can be either single-ended or differential. This device has a built-in clamp amplifier whose clamp input level can be driven from an external dc source or from an internal high-precision 10-bit digital clamp level programmable via an internal CLAMP register. A 3-bit PGA is included to maintain SNR for small signals. The THS1031 provides a wide selection of voltage references to match the userâ€™s design requirements. For more design flexibility, the internal reference can be bypassed to use an external reference to suit the dc accuracy and temperature drift requirements of the application. The out-of-range output indicates any out-of-range condition in THS1031â€™s input signal. The format of digital output can be coded in either unsigned binary or 2s complement. The speed, resolution, and single-supply operation of the THS1031 are suited to applications in set-top-box (STB), video, multimedia, imaging, high-speed acquisition, and communications. The built-in clamp function allows dc restoration of video signal and is suitable for video applications. The speed and resolution ideally suit charge-couple device (CCD) input systems such as color scanners, digital copiers, digital cameras, and camcorders. A wide input voltage range between REFBS and REFTS allows the THS1031 to be applied in both imaging and communications systems. Datasheet I only ship to buyer's EBAY shipping address IMPORTANT: Buyer controls combining of order, by making a single payment for all items. Multiple payments void any shipping discounts. Can only combine BEFORE payment, never after. How to combine orders. If you have ANY time constraints, contact seller BEFORE buying or bidding, so we can BOTH come to an agreement. INTERNATIONAL shipments will NOT have online tracking , unless you use REGISTERED MAIL -- contact seller for invoice. INTERNATIONAL transit time can be 6-28 business days, and can be delayed by local Customs backlogs. If this is not acceptable, we cannot not enter into any trade. US shipments can take 5-7 business days - however the USPS does NOT guarantee these transit times, and can exceed them. eBay tracking info has 24-48 hrs update latency and can only guarantee a delivery scan -- interim scans may not occur. ALL items shipped to buyer's Registered eBay shipping address address, without exception. We can never take an address from email. Payment closes order. No changes are possible once paid. We have no expedited shipping service outside USA -- If urgent, please source locally. International : If you want seller to be responsible for package in transit , you must choose Registered mail - adds $13 to S&H - contact seller for invoice. supreme supremewidgets supremeauctiononlinesoftware.widgets.EbayGalleryZ.swf supremewidgets supremeauctiononlinesoftware.widgets.GalleryCat.swf supremewidgets supremeauctiononlinesoftware.widgets.FeedbackWidgetBasic.swf
