Aemc Ground Resistance Tester 6471 Kit-300ft (model 6471 & Cat. #2135.36)

US $650

Melrose, Massachusetts, United States
Jun 9th

Open on mobile:
QR code

Subscribe to Our Newsletter AEMC 6471 Kit-300ft Ground Resistance Tester (#213550) Brand: AEMC Model Number: 6471 KIT-300FT Ref No: 6471KIT300FT Condition: NEW UPC: 685338130430 Product Overview Features Two SR182 current probes Optical USB cable Two 300 ft color-coded leads on spools (red/blue) Power adapter 110/240V with power cord 115V US Two 100 ft color-coded leads (hand-tied, green/black) Four T-shaped auxiliary ground electrodes Set of five spaded lugs One 100 ft AEMC tape measure Rechargeable NiMH batteries DataView software Ground tester workbook CD Carrying bag for meter Carrying bag for kit Description The Ground Resistance Tester Model 6471 is a portable measurement instrument designed to measure Ground Resistance with 2 clamps (no auxiliary rods), Bond/Connection Resistance (2-Pole and 4-Pole Kelvin sensing), Ground Resistance (3-Pole or 4-Pole), Ground Coupling Resistance, and Selective Ground Resistance, Soil Resistivity (Wenner or Schlumberger method). The Model 6471 measures from 0.01 to 99.99k? and is auto-ranging, automatically seeking out the optimum measurement range, test frequency and test current. Easy-to-use - Simply connect the leads, select the test mode, press Start and read the results. Up to 512 test results can be stored in internal memory for later recall to the display or downloaded to a PC via DataView software.|The Model 6471 is Cat IV rated to 50V and is over voltage protected to more than 250VAC against accidental connection to live circuits. The voltage is also displayed on screen. In the event of a system fault, the Model 6471 can withstand 250VAC.|Additional features of the Model 6471 include a heavy-duty field case sealed against dust and water when closed (the test button is also sealed against the elements); manual and automatic test frequency selection from 41 to 513Hz; user selectable 3-Pole Fall of Potential or 4-Pole Soil Resistivity test methods and user selectable 2-Pole or 4-Pole Bond Resistance test method. The Ground Resistance Tester Model 6471 is rugged, easy-to-use and ideal for maintenance crews performing numerous tests. It exceeds mechanical and safety specifications for shock, vibration and drop tests per IEC standards. The adjustable test frequency provides for rejection of high levels of interference, allowing it to be used under difficult conditions such as high stray currents that affect accuracy.|The 4-Point Bond test displaying lead connections, bond resistance test results, test voltage and current.|The 3-Point Fall-of-Potential test displaying test lead connection, grounding electrode resistance, test voltage and frequency.|The 2-Clamp method displays clamp connection resistance, test current and frequency.|Memory Recall displays test results stored at a specific memory location. Terms & Conditions Please note estimated delivery time above. Contact us for details or if you have a delivery requirement. We ask for your patience while striving to ensure your shipment arrives quickly and accurately. Domestic Shipping FREE Standard Shipping on items OVER $75 to continental U.S. Add $24 for AK, HI, or PR. PO Boxes/APOs require USPS shipping and may therefore experience longer lead times 6.25% Sales Tax for shipping to MA International Shipping Due to international voltage requirements, please ask us prior to purchasing to confirm your product will operate correctly in your country. Please contact us for shipping rates to any overseas U.S. territories. International customers are responsible for all shipping charges, including any duties or taxes.
