Agilent / Hp Hp 8620c Sweep Oscillator W/ 86220a (.01 - 1.3 Ghz)

US $980

Fairfax, Virginia, United States
May 26th

Open on mobile:
QR code

All operating functions tested and verified Operators manual on CD included Agilent-Keysight 8620C The 8620C Sweep Oscillator Mainframe is a versatile mainframe which uses the popular 86200 Series plug-ins (sold separately) to provide capabilities required in a wide range of applications. With appropriate plug-ins, testing digital and analog microwave radio systems and components is easy and affordable. Up to four separate bands and their frequency scales can be selected with a band select lever. Modulation is possible utilizing the internal AM 1kHz or external FM, based on the RF unit. The 8620C supplies three markers and offers sweep functions of The 8620C features full Sweep, Marker Sweep, CW / Delta F, and CW; sweep modes include Auto, Line, and External. The 8620C also includes inputs for band selection, sweep function selection, and analog frequency control. Plug-ins sold separately. Sweep modes are Auto, Line & External Modulation is internal AM 1kHz & external FM based on RF unit Plug-ins sold separately. Options: 011 = HP-IB Frequency Programming Agilent-Keysight 86220A The 86220A Sweep Oscillator Plug-In covers from 10MHz to 1.3 GHz with continuous sweeping capability. Internally leveled flatness of +/- 0.25 dB over full range. Basic accuracy in CW mode is +/- 10MHz and +/- 15MHz in all sweep modes. Maximum leveled power of 13 dBm (20 mW); typically 15 dBm. Power level accuracy of +/- 1 dB. Frequency response of 150kHz, typically. For use in the 8620C Mainframe.
