Aluminum Injection Mold Base B Style 10 X 12 7075 Prototype Plastic Molding

US $1,737.00

Hamilton, Ohio, United States
Jan 30th

Open on mobile:
QR code

Description High Quality B style mold bases – shipped directly to your shop from ours….Machined from 7075, QC10 and Alumold aluminum….We build into our bases the features that are characteristic of all well made molds ….. ….Heat treated Leader pins and bushings….Vented leader pins….pry slots between plates….beveled edges on corners …ground parting line surface….Return pins....three piece bolted ejector housing….tubular dowel construction on A style…AND ….Proudly made in the USA. Lowest Prices for Aluminum Molds in the USA!!! - Many Standard sizes ready to ship!!! Aluminum molds are used for both low volume prototype and high volume production molds. The aluminum injection mold base pictured for sale is a precisely machined 10 x 12 B style. A&B plates are 7075 T651 aluminum and remaining parts are 7075 T7 aluminum. Other dimensions (in inches) are as follows: A plates - L x W x H - 10.00 x 12.00 x 1.94 (other thicknesses available on special order) B Plate - L x W x H - 10.00 x 12.00 x 1.94 C height - 3.0 (higher rails are available) Ejector plate thickness - 875 & .62 in x 7.0 wide Clamp plate thickness – .88 Total thickness – 8.64 Locating Ring Dia. 4.000 Shipped without spru bushing hole (can be added with special request) 4- 3/4 dia. pins -1 pin offset Approx. weight – 115 max lbs with pkg. Notice that no rest buttons are needed because the ejector plate has been machined with clearance under it. 1/2 the investment of a steel mold -hundreds of thousands of shots achievable! All the plates are square and parallel within .001 and the total mold thickness is parallel within .0015 after assembly and the parting line ground. We are proud to manufacture a high quality, reasonably priced product and will be glad to promptly answer other questions. A 3D cad file furnished with purchase. We also have other sizes and will send a price list or quote a special size upon request. Please call 513 889 1060 or Email - info@aqmolds.com Contact us by phone for credit card payments or you may prefer to use direct online pay with company check without interest fees. Let us know that you want to purchase this mold and we can possibly expedite shipping for you. Shipping is UPS ground- please call for discounted rates. *10% of your purchase will be donated to be used in countries throughout the world to feed the poor, clothe the naked and give shelter to the homeless.
