American Dynamics Ad2033 Auxiliary Follower

US $535.00

Houston, Texas, United States
Mar 2nd

Open on mobile:
QR code

AD2033 Series Auxiliary Follower • Activates relays in response to a specific auxiliary command (aux 1, 2 or 3) for a group of video inputs • 32 addressable Form-C relays • Multiple units can be cascaded to provide additional outputs • Diagnostic LEDs • Universal wall, surface or rack mount. SPECIFICATIONS Model Numbers AD2031 . . . . . . . . . . . . . . . . . . . . . .Switcher/Follower, 120 VAC, 50/60 Hz AD2031-1 . . . . . . . . . . . . . . . . . . . .Switcher/Follower, 230 VAC, 50/60 Hz AD2033 . . . . . . . . . . . . . . . . . . . . . .Auxiliary Follower, 120 VAC, 50/60 Hz AD2033-1 . . . . . . . . . . . . . . . . . . . .Auxiliary Follower, 230 VAC, 50/60 Hz Operational Relay Outputs . . . . . . . . . . . . . . . .32 Form-C relays, 2 groups of 16 outputs Address Range AD2031, AD2031-1 . . . . . . . . .2 groups of 16 relays, each group individually set for a specific video output (1 to 128) and contiguous block of 16 video inputs, address range 1 to 1024 AD2033, AD2033-1 . . . . . . . . .2 groups of 16 relays representing video inputs addressable as one of three possible auxiliary contacts LEDs . . . . . . . . . . . . . . . . . . . . . . . . .Power and data Matrix Switcher . . . . . . . . . . . . . . .AD High Speed Data Line and/or Manchester Code connection (See Matrix Switcher data sheet for details) Connectors AD High Speed Data Line . . . . .BNC, in/out AD Manchester Code . . . . . . . . . .One 12-pin removable screw terminal Alarm Output . . . . . . . . . . . . . . . .Eight 12-pin removable screw terminals Electrical Supply Voltage AD2031, AD2033 . . . . . . . . . . .120 VAC, 50/60 Hz AD2031-1, AD2033-1 . . . . . . .230 VAC, 50/60 Hz Power Consumption . . . . . . . . . .8 watts (nominal) Mechanical Dimensions (H x W x D) . . . . . . .89 x 483 x 203 mm (3.5 x 19 x 8 in) Mounting . . . . . . . . . . . . . . . . . . . .Universal wall, surface and rack (19-inch EIA) Unit Weight . . . . . . . . . . . . . . . . . .3.2 kg (7 lbs) Shipping Weight . . . . . . . . . . . . . .4.5 kg (10.1 lbs) Environmental Operating Temperature . . . . . . . .0° to 40° C (32° to 104° F) Storage Temperature . . . . . . . . . .-40° to 70° C (-40° to 155° F) Humidity . . . . . . . . . . . . . . . . . . . . .98% RH (non-condensing) Regulatory Emissions . . . . . . . . . . . . . . . . . . . .EN55022 Class B conducted Immunity . . . . . . . . . . . . . . . . . . . .EN50130-4 Safety . . . . . . . . . . . . . . . . . . . . . . . .UL2044 Compatible Matrix Switcher/Controller Systems MegaPower 1024 Series MegaPower 168 Series MegaPower 48 Series AD2150 Series Basic System Diagram AMERICAN DYNAMICS AD2031 AND AD2033 SERIES FOLLOWER ACCESSORIES VS288 The AD2033 Series Auxiliary Followers interface with American Dynamics Matrix Switcher/Controller Systems to provide switching of external circuits synchronized with the switching of auxiliary contacts that are associated with individual video inputs. The Auxiliary Follower provides two groups of sixteen addressable Form C relays which may be set to follow one of three possible auxiliary actions for each video input. Auxiliary actions may be controlled either manually (through the keyboard) or automatically (upon receipt of an alarm signal). Relays can be used to activate auxiliaries, such as auxiliary lighting and graphic display panels, and they can be tied in to coordinate with an alarm call-up. Multiple units can be cascaded to provide additional relay closures for additional cameras. The universal rack mount enables mounting to the front or rear of equipment racks, or flat on a wall or horizontal surface.

“Like New Coditions”

Brand	American Dynamics
Model	AD2033
