Ametek Usg 3000 Psi Pressure Guage/solfrunt® 4-1/2" Model 1981

US $20.00

Nashwauk, Minnesota, United States
Mar 12th

Open on mobile:
QR code

SOLFRUNT® 4-1/2" Model 1981 and Model 1981 Advantage with Dampened Movement DESCRIPTION The Model 1981 and 1981 Advantage 4-1/2" process gauges have all 316L stainless steel wetted surfaces with a seamless Bourdon tube. The 1981 Advantage includes a dampened movement option to provide users with some of the benefits of liquid filling. These gauges have a PET turret style case for chemical and petrochemical processing applications. The PET material gives this case superior impact strength and a broad spectrum of chemical resistance. They are available dry, with a dampened movement, or liquid filled from the factory. Your local stocking distributor can provide a liquid fill kit, or the E-Z Fill design to facilitate filling in the field without special tools. The Model 1981 and 1981 Advantage 4-1/2" SOLFRUNT gauges are supplied in 26 vacuum, com- pound, and pressure ranges from 30" Hg vacuum through 11600 psi. The low-connected PET turret case can be easily liquid filled in the field using the appropri- ate conversion kit. Span adjustments can be accomplished from rear of case without disturbing the gauge internals. Pointer ad- justments are easily made by removing ring and window, and using the adjustment screw on the micro-adjustable pointer. SOLFRUNT Model 1981 SPECIFICATIONS SIZES: 4-1/2" ACCURACY: ±0.5% of span (Grade 2A), except where seamless stainless steel bourdon tubes are used in following ranges: Type 316L from 10000 to 11600 psi; accuracy is ±0.5% on ascending pressure and ±1.0% on descending pressure BOURDON TUBE: 316L seamless stainless steel/TIG welded WINDOW: High temperature acrylic, laminated shatter-resistant glass options available (G038312) MOVEMENT: Geared movement with components of corrosion- resistant 300 series stainless steel; optional dampened movement available on Advantage unit DIAL: Aluminum with baked white background and black markings (dual scale and custom dials available) POINTER: Anodized aluminum, micro-adjustable with black finish (optional lazy hand, 132371 for dry gauges only) CASE AND RING: For Stem or Wall Mounting: PET turret case (black) with glass-filled polypropylene threaded ring and pressure-relieving back, EZ Fill option available CONNECTION: 316L stainless steel, 1/2-14 ANPT standard (1/4- 18 ANPT, optional) LIQUID FILLING: The Model 1981 is also available in liquid filled or field fillable (E-Z Fill) configurations. SOLFRUNT Model 1981 Advantage with dampened movement

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

Brand

AMETEK
