Aomway 5.8g 500mw Audio/video Av Transmitter + 5.8g Receiver W/antenna Gi

US $113.61

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Aomway 5.8G 500mW Audio/Video AV Transmitter + 5.8G Receiver w/Antenna for FPV RC Model Description: Aomway 5.8G 500mW DC7-16V Audio/Video AV Transmitter + Receiver w/3.5dbi Antenna for FPV RC Model Features: - Upgrade video circuit and sensitivity, with 1W telemetry, could fly 32KM - The lightest transmitter, only 17g - With 3.5dbi omni directional antenna, improve the AV transmission distance and quality Transmitter Specifications: - Weight: 17g - Size: 5.5*2.7*0.7cm - Wide voltage input: DC7-16V - Consumption: 12V 220mA 15% fluctuate - Power: 500mW/26.5dBm - Dual frequency point: 5740-5860Mhz(Fatshark)/5705-5946Mhz(common) - 15 transmite channel: CH-1 7/CH-2 8 - Audio: Left/Right stereo - Format: PAL/NTSC - Output voltage: 5V-12V Dial SMT switch button, choose Fatshark frequency band or common band Power Supply Diagram Receiver Features: do not inclued the DVR video recording function - 5.8G receiver, 32 frequency point, cover almost all frequency band - Frequencyband and frequency point independant display, aovoid mistake - Upgrade video circuit and sensitivity, with 1W telemetry, could fly 32KM Receiver parameters: - Working Frequency: 5740-5860MHz (Fatshark dedicated ) / 5705-5945MHz ( Universal ) 5733-5866MHZ/5725-5865MHZ - Wide input voltage : 7V-16V - DC 12V,170mA - 15 transmit channels : CH-1 7channels CH-2 8channels - Sound: about two-channel stereo output - AV Video Output: 2 AV output - Weight : 126g - Size : 80 * 70 * 25mm Frequency Band Package Included: - 1* 500mW Transmitter - 1* 5.8G RX004A Receiver (without DVR Function) - 2* 3db Antenna - 2* DC cable - 3* Video cable Shipping & Payment: Here Offer 100% Satifiation Service,Inlucde re-send item&refund payment; All items here offer 1 year warranty It is not my Duty for Custom Tax All items will be shipped via int'l air mail( no tracking number for items under $50), the time normally takes 7-15 business days. may be later arrivel if the item is checked by custom; We only accept paypal payment.
