Applent At2817a Lcr Meter Rs232c/exhander 50hz-100k Hz 16 Point L C R Z D Q

US $938.00

ShenZhen, China
Jan 29th

Open on mobile:
QR code

Overview: * The AT2817A is the use of a high-performance processors and highlight color LCD screen smart LCR Meter. Since the SMD technology makes AT2817A portability. We rely on highly skilled technical, so that the instrument even more outstanding performance. * AT2817A offers wide frequency range (50Hz-100kHz 16 points), programmable signal level (0.01V to 2.00V), auto range with 9 ranges, 30 ohm or 100 ohm constant output impedance and easy-to-use operation system. * Built-in RS232C and handler interfaces help build an automatic component test system, communicate with the computer and analysis the test results. Specification: * Parameters: Cs-Rs,Cs-D,Cp-Rp,Cp-D,Lp-Rp,Lp-Q,Ls-Rs,Ls-Q,G-B,R-X,Z-?rad,Z-?deg * Monitor Parameters: Z, D, Q, ?r, ?d, R, X, G, B, Y, Vac, Iac, ?, ?% * Accuracy: 0.05% * Frequency: 50Hz-100kHz 16 points * Display Range: L 0.00001uH-999999H; C: 0.00001pF - 999999uF; R,Z 0.00001 ohm-99.9999M ohm; D,Q 0.00001 - 999999; ?% -999999% - 999999% * Source Resistance: 30 ohm 50 ohm 100 ohm * Range: 9 ranges Automatic, Manual, Nominal * Display Max: principle parameter: 999999; sub parameter: 999999 * Signal Level: 0.01V - 2.00V (10mV Step) * Speed: 30 t/s, 10 t/s, 6 t/s, 3 t/s 1 - 256 times average is available * Comparator: 14-bin sorting, 10-bin GD, 1-bin NG, 1-bin AUX, 2-bin principle parameter NG * Adjustment: Open/Short sweep frequency reset, 3 point frequency and load correction * Files: 10 group files to save users' setting, 1 group system data save real-time * Interface: RS232C, ExHandler Interface, with standard USB disc interface (article 10000 data) * Others: LCR automatic selection, keypad lock, SCPI instruction set, true-color TFT-LCD display Voltage: 90V AC - 250V AC Frequency: 50Hz - 60Hz Power: Max 20VA(If you need 120V, please contact us first, sometimes has not stocks) 264mm(Width)x107mm(Height)x350mm (Depth); 4kg ATL501: Test cable ATL607: Test fixture ATL600: Short-circuit slice ATL801: 232 Communication cable ATL608 SMD patch clamp ATL508: SMD patch test clip ATS2818: Data acquisition software ATL508A: SMD patch test clip Feature: * 3-line VFD Display * Correction: OPEN and SHORT * View: ?ABS, ?% or Sorting Result on 3rd Line * Comparator Function: 10 files,14 bins: P1-P9,NG,AUX, HI, IN, LO * Interface: RS232C and Handler * Optional Interface: USB * Test signal monitor: Vm and Im * Avarage rate: 1~99times * Measurement Terminal: 5 terminals * Key lock function (1). Note: (1.1). This item is shipped by EMS/Fedex/DHL to E.Asia/N.America/W.Europe, other area by China post(Shipping time about 4-6weeks); (2). Problem solve, leave Feedback and DSR: Our no.1 goal is customer stasfaction. If there is any problem, please contact us before leave feedback and DSR.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Applent
Model	AT2817A
