Applent At2818 Tft Lcr Meter Rs232c/exhander 10hz-300k Hz 0.001hz Step L C R Z D

US $2,588.00

ShenZhen, China
Jan 29th

Open on mobile:
QR code

Overview: * AT2818 adopts true-color TFT-LCD and English operation interface (Chinese is also available). AT2818 (Rev B2.0) has been upgraded into continuous frequency with the resolution of 0.001Hz. * Four parameters can be measured at the same time by AT2818, any parameters can be set arbitrarily. Both main & sub parameters can be displayed in 6 dgt after the improvement. AT2818 can not only scan 10 kinds of frequency or voltage level, but also correct three groups of user frequency so as to improve the accuracy. Specification: * Parameters: Cs-Rs,Cs-D,Cp-Rp,Cp-D,Lp-Rp,Lp-Q,Ls-Rs,Ls-Q,Rs-Q,R-X,Z-?rad,Z-?deg * Monitor Parameters: Z, D, Q, ?r, ?d, R, X, G, B, Y, Vac, Iac, ?, ?% * Accuracy: 0.05% ±5 * Frequency: 10Hz-300kHz, 0.001Hz step * Display Range: L: 0.00001uH - 999999H; C: 0.00001pF - 999999uF; R,Z: 0.00001 ohm - 99.9999M ohm;? D,Q: 0.00001 - 999999; ?(deg): -90.0000 degree - 90.0000 degree; ?(rad): -3.14159 – 3.14159; ?%: -999.999% - 999.999% * Source Resistance: 30 ohm 50 ohm 100 ohm * Range: Automatic, Manual, and nominal, 9 ranges * Display Max: 6 digital, principle parameter: 999999; sub parameter:999999; monitor parameter: 999999 * Signal Level: 0.01V - 2.00V (10mV Step) * Speed: 30t/s, 10t/s, 6 t/s, 3 t/s 1-256 times average is available * Comparator: 14-bin sorting, 10-bin GD, 1-bin NG, 1-bin AUX, 2-bin principle parameter NG; Count Function: Max - 999999 * List Test: 10 group frequency and level scanning measurement * Adjustment: Open and Short circuit sweep frequency reset, 3 point frequency reset and load calibration. * Files: 10 group files to save user's setting, 1 group to save system data real-time * Interface: RS232C, ExHandler interface, standard configuration USB Disc interface(article 10000 data) Feature: * TFT-LCD Display * Correction: OPEN and SHORT * Comparator Function: 10 files,14 bins: P1-P9,NG,AUX, HI, IN, LO * Interface: RS232C and Handler * Optional Interface: USB-Disk and USB-232 * Test signal monitor: Vm and Im * Avarage rate: 1-200times * Measurement Terminal: 5 terminals * Key lock function (1). Note: (1.1). This item is shipped by EMS/Fedex/DHL to E.Asia/N.America/W.Europe, other area by China post(Shipping time about 4-6weeks); (2). Problem solve, leave Feedback and DSR: Our no.1 goal is customer stasfaction. If there is any problem, please contact us before leave feedback and DSR.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Applent
Model	AT2818
