Asymtek Century C-702 Automated Dispensing System

US $12,499.99

Phoenix, Arizona, United States
Jan 30th

Open on mobile:
QR code

Click Here. Double your traffic. Get Vendio Gallery - Now FREE! Asymtek Century C-702 Automated Dispensing System Comes with a manual and what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Asymtek and may vary slightly due to upgrades, options, or revisions this unit may or may not have. The unit has FMnT 4.5 installed and there was a note saying the previous owner removed the system on 12/8/2009 and tested the X-Y system before removing it from service and the computer communications to make sure they were fine. They could not test the compressed air functions because of a modification that they removed that was custom to them. It appears to have all the dispenser heads removed. The monitor is not included. Spare parts that were listed on packages include: Syringe & Valve Mounts for Z-Stage, Asymtek Dispenser Panel (Bad Fast X-Y slow tactile buttons), 4 shipping brackets. OEM External I/O Cable (P/N: 06-2143-00, Rev E), Extra Scrolling Mouse, Fluidmove FMNT 4.5 (P/N: 198896 Rev A) CD. The Unit's Serial Number Tag Reads: Serial Number: 7557 Standard Features: Excellent X-Y placement accuracy of 0.13 mm (0.005") Key safety features meet CE standards Emergency stop button (E-STOP) quickly removes all system power ESD-resistant front doors with safety interlock Clear side panels and integrated lighting allow viewing of dispensing area Membrane front panel is resistant to corrosive fluids and easily cleaned Integrated I/O, with 24 user-accessible inputs and outputs Closed-loop velocity control on front panel Description: The Century Series automated fluid dispensing system is capable of handling a wide range of industrial and electronic applications. The Century Series represents an evolution of the industry-preferred A-400 Series of fluid dispensers from Asymtek, providing low cost of ownership in a versatile, CE-approved package. The Century Series integrates safety standards and automated fluid delivery in an attractive, ergonomic design. The system features a membrane front panel that is divided into functional areas of operation: Programming, Run, System Status and Safety Interlock. Programming is done with Asymtek's Fluidmove software, an easy-to-use interface supporting the unique needs of fluid dispensing applications. Model C-702 provides a 305 x 305 mm (12 x 12") dispensing area. Absolute positioning accuracy of ±0.13 mm (0.005") applies over the entire work area. In addition, Century Series systems incorporate many automated fluid dispensing functions, including closed-loop velocity controlled auger pump valves, safety doors for interlock, system status lamps and 24 opt-coupled inputs/outputs. A ground nickel-plated tooling plate and alignment bars allow for flexible part positioning. Users may add many dispensing options offered by Asymtek, such as an automatic vision system, height sensor, needle sensor, light curtains, a dual-action dispensing head, heated tooling and an ergonomically designed workstation (This unit appears to have the automatic vision and needle sensor, the vision is a guess though because it has Cognex installed on the computer). Drive System Specifications: X-Y Axes Speed: 508 m/s (20"/s.) max., 381 mm/s (15"/s.) default Control: Brushless DC Stepper Motor System Repeatability: ±0.025 mm (0.001") System Resolution: ±0.025 mm (0.001") Placement Accuracy: ±0.13 mm (0.005") Z-Axis Speed: 203 mm/s (8"/s) max., 51 mm/s (2"/s) default Z-Axis Repeatability: ±0.025 mm (0.001") Z-Axis Resolution: ±0.025 mm (0.001") Dispensing Area Specifications: C-702: 305 x 305 mm (12" x 12") Valves Specifications: Valve selection subject to fluid properties and application. Facilities Requirements: System Footprint: Approx. 44" D x 34" W x 56" H Power: 100/120/220/240 VAC, 50/60 Hz, 200 Watts Air Pressure: 690 kPa, (90 psi) Air Volume: 28 liters/min. (1 CFM) Noise: <70 dBA Environmental: 5-55°C, 5-90% RH (below 40°C) Approx. Weight: 389 kg (858 lb.) with workstation For More Pictures Please Click the Following: Picture 2 - Back View Picture 3 - Right Side Picture 4 - Left Side Picture 5 - Front Panel Controls #1 Picture 6 - Front Panel Controls #2 Picture 7 - Front Panel Controls #3 Picture 8 - Dispensing Area, Front View, Doors Open Picture 9 - Needle Sensor Picture 10 - Dispensing Area, Right Side Picture 11 - Dispensing Area, Left Side Picture 12 - Computer Screen Showing Software Installed Picture 13 - Bottom Cabinet Open, Computer and Parts Picture 14 - Back of the Computer Picture 15 - Computer's Serial Number Tag Picture 16 - Main Unit Serial Number Tag $150.00 minimum for packaging, handling, and order processing. Shipping to be determined by destination. If you have any questions please email us at: ebay@mhzelectronics.com or call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 03/22/10 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
