Av-10 Ramp Test For Mode A/c/s Transponder Ads-b, Vor, Ils, Dme

US $995.00

Titusville, Florida, United States
Jan 29th

Open on mobile:
QR code

Condition = NEW Part Number = AV-10 RAMP TESTER The AV-10 is a small, low cost, easy to use instrument that provides test signals for the following aircraft avionic systems: 1. Generates VOR test signal's at each 45 deg radial at Carrier frequencies of 108.0, 110.2, 112.4, or 113.6 MHz. Also generates ID tone. 2. ILS test signals. a) Localizer 108.1 or 110.3 MHz carrier frequency. Center, 1/2 and full deflection right and left, 150Hz or 90Hz only modulation to check NAV flag. Also ID. b) GLIDE SLOPE 108.1 - 334.7, or 110.3 - 335.0 MHz carrier frequency. Center, 1/2 and Full deflection up and down, 150HZ or 90Hz only modulation to check flag. c) MARKER BEACON 75MHz AM modulated signal. Beep rate is slowest at outer marker. Generates OUTER, MIDDLE, and INNER marker beacon signals. 3. DME test signal. 108.00 =17X or 108.05=17Y MHz carrier selectable. Generates a fixed 20NM signal to DME. 4. ADF-NDB test signals. Selectable 400KHz, 450KHz, 650KHz and 1200KHz AM modulated low level signals to check basic ADF operation. 5. TRANSPONDER A/C/S ADS-B 1090ES a) Generates standard ATCRBS MODE-A test signal and display's squawk code and reply percentage. Also allows sidelobe suppression check. If the transponder IDENT is activated then the AV-10 will also display IDENT. 235 PRF b) Generates ATCRBS MODE-C test signal and display's altitude and reply percentage. Also allows sidelobe suppression check. 235 PRF c) checks the Aircraft Transponders Transmit carrier frequency. d) Measures ATCRBS transponders Side Lobe Suppression time. e) sends A/C/S ALL-CALL message. reads mode-s reply. f) ATCRBS only all-call. looks for eronious mode-s reply's. g) send MODE-S only ALL-CALL. reads mode-s reply. h) UF=4 discrete addressed MODE-S altitude read. Adjustable address. i) UF=5 discrete addressed MODE-S ID or squawk read. Adjustable address. j) DF=20 discrete addressed aircraft tail number read. Adjustable address. k) DF=21 discrete addressed capability report read. Adjustable address. l) ADS-B MODE-S ID SQUITTER read. m) AIRCRAFT TAIL NUMBER SQUITTER read. n) LOCATION SQUITTER read. Size=6.25"L x 3"W x 2"H plus antenna Weight= about 1 pound Runs on (4) AA batteries. Comes with antenna and batteries in foam lined plastic carry case. New with 30 day refund, buyer pays return shipping & insurance. Free ground shipping to continental US. See factory web site for more info; sunavionics.com

Condition:	New	Manufacturer Part Number	AV-10
Part Brand	Sun Avionics, Inc.
Warranty	Yes
Country of Manufacture	United States
