Belden 8104. 24/4pair Low Capacitance Computer Cable. 1000' Gray Reel.

US $800.00

New York, New York, United States
Jan 29th

Open on mobile:
QR code

You are bidding on a 1000' reel of Belden 8104 Cable. This is a 24 awg 4 pair Low Capacitance Computer Cable. This wire has a Chrome (Gray) jacket. Please email me with any questions. Description: 24 AWG stranded (7x32) TC conductors, Datalene® insulation, twisted pairs, overall Beldfoil® (100% coverage) + TC braid shield (65% coverage), 24 AWG stranded TC drain wire, PVC jacket. Physical Characteristics (Overall) Conductor AWG: # Pairs AWG Stranding Conductor Material 4 24 7x32 TC - Tinned Copper Insulation Insulation Material: Insulation Trade Name Insulation Material Datalene® FPE - Foam Polyethylene Outer Shield Outer Shield Material: Layer # Outer Shield Trade Name Type Outer Shield Material Coverage (%) 1 Beldfoil® Tape Aluminum Foil-Polyester Tape w/Shorting Fold 100 2 Braid TC - Tinned Copper 65 Outer Shield Drain Wire AWG: AWG Stranding Drain Wire Conductor Material 24 7x32 TC - Tinned Copper Outer Jacket Outer Jacket Material: Outer Jacket Material PVC - Polyvinyl Chloride Overall Cable Overall Nominal Diameter: 0.279 in. Pair Pair Color Code Chart: Number Color 1 White/Blue & Blue/White 2 White/Orange & Orange/White 3 White/Green & Green/White 4 White/Brown & Brown/White Mechanical Characteristics (Overall) Operating Temperature Range: -30°C To +80°C UL Temperature Rating: 80°C (UL AWM Style 2919) Bulk Cable Weight: 47.500 lbs/1000 ft. Max. Recommended Pulling Tension: 49.500 lbs. Min. Bend Radius (Install)/Minor Axis: 3 in. Page 1 of 3 02-24-2012 Detailed Specifications & Technical Data ENGLISH MEASUREMENT VERSION 8104 Multi-Conductor - Low Capacitance Computer Cables for EIA RS-232/422Applicable Specifications and Agency Compliance (Overall) Applicable Standards & Environmental Programs NEC/(UL) Specification: CM CEC/C(UL) Specification: CM AWM Specification: UL Style 2919 (30 V 80°C) EU CE Mark: Yes EU Directive 2000/53/EC (ELV): Yes EU Directive 2002/95/EC (RoHS): Yes EU RoHS Compliance Date (mm/dd/yyyy): 01/01/2004 EU Directive 2002/96/EC (WEEE): Yes EU Directive 2003/11/EC (BFR): Yes CA Prop 65 (CJ for Wire & Cable): Yes MII Order #39 (China RoHS): Yes Flame Test UL Flame Test: UL1685 UL Loading Plenum/Non-Plenum Plenum (Y/N): No Plenum Number: 88104 Electrical Characteristics (Overall) Nom. Characteristic Impedance: Impedance (Ohm) 100 Nom. Capacitance Conductor to Conductor: Capacitance (pF/ft) 12.5 Nom. Capacitance Cond. to Other Conductor & Shield: Capacitance (pF/ft) 22 Nominal Velocity of Propagation: VP (%) 78 Nom. Conductor DC Resistance: DCR @ 20°C (Ohm/1000 ft) 24 Nominal Outer Shield DC Resistance: DCR @ 20°C (Ohm/1000 ft) 4.1 Max. Operating Voltage - UL: Voltage 30 V RMS (UL AWM Style 2919) 300 V RMS Max. Recommended Current: Current 1.5 Amps per conductor @ 25°C Notes (Overall) Notes: Datalene® insulation features include low dielectric constant and a dissipation factor for high-speed, low-distortion data handling. Physical properties include good crush resistance and light weight. Please note that sales tax will be added to the following states: AZ, AR, CA, CO, CT, FL, GA, ME, MD, MN, NE, NV, NJ, NY, OH, PA, SD, TX

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Belden
MPN	8104
