Biesse Skipper 100 Cnc Router-woodworking

US $5600

Southeast USA, United States
May 25th

Open on mobile:
QR code

CMS 5869 Woodworking-CNC Router Manufacturer: Biesse Model: Skipper 10 YMFG: 2007 Condition: As Taken From Service Location: Southeast USA Price: Call for Price Manufacturer specs (to be confirmed): PLATE SIZES: Length 90 - 3,000 mm Width 70 - 1,000 mm 8 Thickness (*) - 60 mm (*) The length of the plate area. 2000 mm thickness min. is 13 mm SCOPE OF WORK TOOLS (refer to the size of the tool axis) The X axis (length) Vertical holes 0 - 3 000 mm Horizontal holes in X 0 - 3 000 mm Horizontal holes in the Y 0 - 3 000 mm Milling continued (with electrospindle) 0 - 2 500 mm Milling partial (with electrospindle) 0 - 3 000 mm Continuous feeds (with the ball) in the direction of X 0 - 2 500 mm Partial channels (the ball) in the direction of X 0 - 3 000 mm The Y-axis (width) Vertical holes in the Y 0 - 1 000 mm Vertical holes from the "System 32" 32 - 1 000 mm Horizontal holes in X 0 - 1 000 mm Horizontal holes in Y 90 - 1 000 mm Milling (using electrospindle) 0 - 950 mm Channels (the ball) in the direction X 112 - 1 000 mm Z-axis (thickness) 0 - 60 mm OPERATING UNIT Skipper has independent spindles 78, 39 on top of the operating units and the lower 39 units , two operating units in mirror image, with the following configuration: 29 independent vertical spindles with a wheelbase 32 mm, of which 19 along the X axis (System 32), and 10 along the Y axis 8 independent spindles positioned along the horizontal X (4 dual output) Two independent horizontal spindle positioned in the negative Y direction. CONTACT: RALPH VIEGELMANN 704-288-1904 X 101 LINK TO MACHINE: http://www.carolinamachinerysales.com/?page=detail&id=used&machine=5869
