Bnc Ramp Generator Lg-1 Lg1 Lg 1 Nim Module

US $50.00

  • Sparta, Tennessee, United States
  • Jan 29th
Open on mobile:
QR code
BNC Ramp Generator Model LG-1 OUTPUT Amplitude: 25 mV below the baseline to 11.7 volts above baseline, adjustable. Output Impedance: 100 ohms. GENERAL Linearity: Integral, better than +/-0.02%; Differential, better than +/-0.1%, to with 20 mV of turn-around points. Max. operating temperature: 55 oC. Output Waveform: Triangular Waveform Power Requirements: +24 V at 90 mA. -24 V at 75 mA. PHYSICAL Size: Single-width AEC NIM module 1.35" wide x 8.70" high in accordance with TID-20893 (Rev. 3). CONTROLS Start: Push button, Ramp is initiated. Stop: Push button, Ramp terminates at end of cycle. Reset: Push button, Ramp is reset to 25 mV below baseline. Period: 5 or 50 sec at max. amplitude of 11.7 volts. Period reduced at smaller amplitude. Polarity: Positive or Negative. Rep / Single Cycle: Toggle to provide continuous or single cycle ramp. Amplitude: Max. amplitude is adjustable by front panel trimmer from 1 to 11.7 V. Offset below baseline is adjustable by internal trimmer from 25 mV to 500 mV This module is in excellent working condition and was recently removed from a working environment! Shows only minimal signs of prior use! Please view our auctions and stores for similar items! THANK YOU For considering our item! We have been selling on ebay for over 12 years! Bid With Confidence!
