Brand New 20mhz Function Generator/counter

US $295.00

Corona, California, United States
Jan 29th

Open on mobile:
QR code

CA1642-20 DDS SIGNAL GENERATOR / COUNTER Click any image to see it full size Item Description Brand New CA1642-20 DDS FUNCTION SIGNAL GENERATOR/COUNTER Product Brief CA1642 series uses the latest Direct Digital synthesis(DDS)technology and FPGA designation to generate stable,high resolution output frequency.duction lines and the teaching and research. Large scale integrated circuits,super-speed ECL, TTL circuits and high-speed micro-processor technique are adopted into the instrument. Anti-interference technique has been improved greatly by surface plating technique in internal circuits.Interactive menu in English is adopted for the operation interface.And the performances of the keys have been improved effectively so that users do not need to operate keys frequently.DDS equipment with dual signal output.This instrument has such signal generating function as,frequency modulation,amplitude modulation, phase modulation,FSK,ASK,PSK,frequency sweeping,phase sweeping,etc,and any counts generation function for function signals. Features ? Excellent DDS and FPGA technology ? Frequency range: 1µHz ~ 10MHz ? Frequency accuracy: 1µHz(Small signal accuracy: 10mV(attenuation 0dB)) ? Adjustable duty cycle of sine,triangle and square wave ? Function of arbitrary ? Function of Counter ? Sub-wave output function ? INT/EXT and AM/FM/PM modulation ? Linear sweep and logarithmic sweep mode ? Waveform storage ? Power output ? USB interface Specifications DDS FUCTION SIGNAL GENERATOR/COUNTER Adjustable duty cycle of sine, triangle and square wave;Function of arbitrary and subwave CA1642-20 DDS FUNCTION SIGNAL GENERATOR/COUNTER Technical Data CA1642-20 Mainwave frequency range 1µHz ~ 20MHz Main output Waveform sine,square,triangle,TTL and arbitrary etc Duty cycle Adjustable (1%~99%) Sine wave harmonic distortion 0.3%(20Hz~2kHz) Square ware rising & falling time 20ns Frequency resolution 1µHz Frequency error ±5x10-6 Frequency stability ±1x10-6 Amplitude range 10mVp-p~20Vp-p Amplitude resolution 10mV Amplitude error ±(1%+2mv)(f<1KHz 20Vp-p) Amplitude stability ±0.5% DC offset +5V~-5v Output impedance 50?±10% Attenuation 10bB 20bB 30bB 40bB 50bB 60bB Sub output Waveform sine,square,triangle Frequency range 10mHz~200kHz Amplitude range 10mVp-p~20Vp-p Output impedance 600?±10% TTL Output Level >=3Vp-p Sweep Range 10mHz~20MHz Time 10ms~50s Mode Linear/ logarithm Amplitude modulation Mode internal and external Frequency 0~200kHz(INT) , 1Hz~100kHz(EXT) Depth 1%-120% External modulation EXT input signal 0-2V peak value (no attenuation) , 0~20V peak value (attenuation 20dB) Frequency modulation Mode internal and external Frequency 0~200kHz(INT) , 1Hz~100kHz(EXT) Depth 100% of the carrier wave frequency External modulation EXT input signal 0-2V peak value (no attenuation) , 0~20V peak value (attenuation 20dB) Phase modulation Mode internal and external Frequency 0~200kHz(INT) , 1Hz~100kHz(EXT) range 0°~360.0° Resolution 1° External measuring Range 1Hz~100MHz Minimal input voltage Internal attenuation on: 1V; Internal attenuation off:100mV Maximal input voltage 20V Measuring time 0.1s (fast) , 1s (slow) Internal lowpass Frequency up to 100kHz (approx) Power source 110 ~ 127VAC±10% 60Hz±2Hz Dimensions(WxHxD) 265*300*110(mm) Weight 2Kg Approx Packing List ? Signal output cables 2 pieces ? USB Line 1 piece ? Power plug 1 piece ? Power fuse 1 piece ? User manual 1 book Payment Details Paypal is the best payment method. Please send your payment to: paypal@omxie.com. We also accept Visa, Master, American Express and Discover card. Please call 1-877-589-9422 to pay with credit card. We require that shipping address matches with your billing address of credit card. Payment must be received within 7 days after auction ends. Shipping Details Shipping UPS ground to 48 continental states costs $20 Shipping to Hawaii, Alaska, PR, APO, FPO add Extra $20 International Bidders Welcome: International packages shipped by UPS (Handling & Insurance included). Shipping cost will be determined by country. Shipping to most areas of Canada area: $50 Estimated Shipping cost to West Europe, Australia: $60 Please email for the shipping cost to other countries. Shipping insurance is required for international shipping. Customs duties and brokerage fees might be possible for some countries. They are buyers' responsibility if there are any. S&H charged dose not include any those fees. We combine shipping for multi-item purchase whenever it is possible, charging full S&H for the first item and half of that from the second (smaller) one on. We do not charge any S&H for real small items if they are combined for shipping with large items. Shipping Insurance is included. Breakage in transit will be replaced or refunded to customer's satisfaction. Local Pick-Up is welcome. Please contact us if you would like to schedule pick-up. All local pick-ups are subject to 8.75% California Sales Tax. We will e-mail tracking number after shipping the product. If you do not receive a shipping confirmation email with tracking # within 48 hours, please email shipping@omxie.com or call 1-877-589-9422 8:30 am-4:30 pm Pacific Time MON-FRI for shipping status. If you have any questions about shipping cost please email shipping@omxie.com or call 1-877-589-9422 Bus. Hr.: 8:30 am-4:30 pm Pacific Time MON-FRI. Additional Information Warranty: All our products carry a standard one year warranty. Service or repair will be done in the US. Consumable parts, like all Heating Elements, will not be covered by this warranty, but replacement parts can be purchased from us. Return and Refund Policies: All sales are final! About us: We engage in research, development and marketing of electronic test and measurement instruments, hot air rework stations, SMT tools and equipment for prototype and small quantity production of circuit boards. We are expanding to biological devices. We also do customer electronic hardware design, software development and outsourcing production. Customer satisfaction is our highest priority. We provide quality products at low prices and excellent services. Contact Us: SMTmax 5675 Kimball Ave, Chino, CA 91710 Toll Free: 1-877-589-9422 Fax: (909) 393-8766 "Your #1 source for SMT Equipment!" · Other Auctions · Auction templates at BiggerBids.com.
