Bridgeport Milling Machine With 2-axis Prototrak (smx) (comes With Tools)

US $13,999.00

Colchester, Vermont, United States
Feb 22nd

Open on mobile:
QR code

This auction is for a Bridgeport milling machine equipped with a 2-axis CNC ProtoTrak SMX system. The auction also includes all the tools and collets shown in the pictures. I purchased this machine for personal use in February 2013, but I have had no time to use it and therefore I have decided to part ways with it. I also have all the owners manuals (Bridgeport, Vari Speed conversion kit, ProtoTrak). Here are the details: Bridgeport milling machine Machine height: 82" Machine gross weight: 2200 lbs Table size: 42" x 9" X-Axis travel: 30" Y-Axis travel: 12" Z-Axis travel: 16" Quill travel: 5" T-Slots: 3 on 2.5" RPM: Low: 60-500 High: 500-4,200 Collet type: R8 Motor: 2.0 HP Power: 208V, 3 Ph, 60 Hz ProtoTrak PTSMX2 This CNC system is very flexible and allows the operator to directly import G code programs, import DXF drawings, or create your own program on the system screen. Control Hardware - 2-axis CNC, 3 axis DRO - Real hand wheel for manual operation - 10.4” color active-matrix screen - Industrial grade Intel Processor - 128 Mb Ram - P/S 2 Keyboard connector - 2 USB connectors - Override of program feedrate - LED status lights built into display - TEAC floppy drive Software - Clear, uncluttered screen display - Prompter data inputs - English language - no codes - Soft keys - change within context - Windows operating system - Color graphics with adjustable views - Inch/mm selectable - Convenient modes of operation DRO mode features for manual machining - Incremental and absolute dimensions - Jog at rapid with override - Powerfeed X, Y - Do One CNC canned cycle - Teach-in of Manual moves - Servo return to 0 absolute - Tools offset from library Program Mode Feature - Geometry based programming - Incremental and absolute dimensions - Automatic diameter cutter comp - Circular interpolation - Linear interpolation - Look-graphics with a single button push - Listed step - graphics with programmed events displayed - Alphanumeric program names - Program data editing - Canned cycles - Position - Drill - Bolt holes - Mill - Arc - Circle pocket - Rectangular pocket - Circular profile - Rectangular profile - Program pause - Conrad - automatic corner radius - Math help with graphical interface - Auto load of math solutions - Tool step over adjustable for pocket routines - Subroutine repeat of programmed events - Nesting Edit Mode Feature - Delete events - Erase program Set Up Mode Features - Program diagnostics - Advanced tool library - Tools names - Advanced diagnostic routines - Software travel limits - Tool path graphics with adjustable views Run Mode Features - Trial run at rapid - Real time run graphics with tool icon Program In/Out Mode Features - Simple program storage floppy - CAM program converter - Converter for prior-generation ProtoTRAK programs Tools & Equipment - Vices with turn table (very little use) - 1/8” steel parallel set - 1/32” thin steel parallel set - 115 piece drill bit set - 1/4” to 3/4” HSS 2F/4F TiC end mills set - Other assorted end mills - Fly cutter - Assorted metric taps - Assorted standard taps - Center drill set - Edge Finder - Dial indicator - T slot hardware and hold downs

“Sold as shown, shows normal signs of wear. See pictures for more details.”

Country/Region of Manufacture	United States
Model	J Series
Brand	Bridgeport
MPN	J-56683
