Broekx 3 Axis Cnc Router Table Milling, Drilling And Engraving Machine Diy Plans

US $36.00

Crystal Brook, SA, Australia
Jan 30th

Open on mobile:
QR code

CNC ROUTER 6050 PLANS This is not a kit, plans only Why not build your own CNC router/engraver with easy to follow comprehensive Scaled Drawings at a fraction of the cost of a bought machine? As the builder of this machine you will understand how it works and take pride in the completed project. Drilling and cutting dimension of all components are supplied, with a comprehensive material list with exploded views on how to assemble. A full set of electrical drawings are included TECHNICAL SPECIFICATION Machine: Model number CNC-6050 Effective working travel 550(X)mm*650(Y)mm*120(Z)mm Work table dimension 844mm*688mm Acceptable material thickness 120mm Driving units X axis 1605 ballscrew with FK-12 and FF-12 Bearings Y axis 1605 ballscrew with FK-12 and FF-12 Bearings Z axis 1605 ballscrew with FK-12 and FF-12 Bearings Sliding units X axis SBR16 chrome plate shafts with SBR16UU Bearings Y axis SBR20 chrome plate shafts with SBR20UU Bearings Z axis Dia.16mm chrome plate shafts with SC16LUU Bearings Stepping motor type 57BYGH76-401A two-phase 2.8A 18.9kg-cm (263 oz-in) Spindle motor 800W spindle, 24000RPM Principal axis collet ER11/3.175 mm/6mm Repeat accuracy 0.05mm Milling/Carving Instructions G code/TAB files/nc file/NCC files Communication interface Through parallel connection with computer Software requirement Windows xp Maximum speed 0-4000mm/min Milling/Carving speed 0-2500mm/min (different materials differ) Construction Material 12mm Aluminium Pate 6061 T651 Control box: Operating Voltage AC110V/AC220V Control unit 24V 17A power supply + TB6560 3 axis drive board Computer connection On board parallel port Command code G code Acceptable software Mach3,EMC2 Protection Emergency stop button Machine features: This CNC-6050 machine is suitable for industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes. It can work with various materials, such as: wood, abs or other plastic, MDF board, native wood, PVC, Acrylic, wood, composite board plywood. And soft metal .like aluminium, copper and silver. etc. It can be used for milling, drilling and engraving: advertising signs, PCB, nameplates, badges, seals, bronzing plate, aluminium alloy, acrylic plates, ABS resin double colour plate, PVC foaming board, indentation plates, signs, construction models, instrument panels, wooden products, etc. These easy to follow plans will be sent to you electronically via email as soon as confirmation of payment is received. You will receive the detailed plans, material list and electrical drawings to construct your own CNC Router 6050. This is not a Kit, Drawing Plans Only License to build one CNC-Router 6050.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	BROEKX
Country/Region of Manufacture	Australia
Model	CNC-6050
