Capacitor Capacitance Esr Meter Tester Combo Dmm Mesr-100 + M4070 Lcr Meter (uk)

US $127.99

default, default, United Kingdom
Jan 29th

Open on mobile:
QR code

???? 1 Capacitor Capacitance Cap ESR Meter Tester Combo DMM MESR-100 + M4070 MIB-INSTRUMENTS THIS LISTING ITEM LOCATION AT UK STORE, CAN SHIP TO UK LOCAL OR EUROPE COUNTRIES IMMEDIATELY. IMPORTANT NOTES:FOR UK Buyers, we ship from UK warehouse for sure. For other countries, shipment method is determined by the Seller. We decide the shipment method that is the most safe and fast for shipping to your country. "Can Buy It Now in my ebay store" Features: JINGYAN MESR-100 V2 Auto-ranging capacitor ESR and Low Ohm Meter Measuring range from 0.001 to 100.0R, support IN CIRCUIT Testing. Using true 100 KHz sine wave to measure the ESR value, which is equal to the testing method of capacitor manufacturer. In the market, there is some technique using short pulse method to testing, but the value will be varying vs the capacitance and sometimes reading is different from the manufacturer's value. What is ESR of capacitor? There is a series resistor inside capacitor, using 100kHz to remove the impedance 1/(2*pi*F*C), the impedance become small, and we can then measure the true series resistor value. A bad E-capacitor will have larger ESR and create large ripple rather than filtering noise. Normally, a big capacitor is larger than 3 ohm. Using this theory, we can measure the capacitor is bad/ damaged or good in condition. Because our ESR meter only applies less than 15mV DC or peak to peak on a good capacitor, as a result we can use it as in circuit test. Because this low testing voltage, it cannot turn on the semiconductor inside a circuit under testing. During repairing TV, LCD, Audio board, etc. we can in circuit testing the capacitor is good or not. *Dual terminal, for fast and easy inspect general capacitor or resistor, a printed ESR table for fast check Compare MESR100 old V1 and new V2 Improvement: 1) Change square wave to sine wave 100 KHz, reduce square wave’s high frequency component, and affect the reading passing the test leads and capacitor. 2) Higher Resolution up to 0.001 ohm. 3) 128X64 dot matrix LCD, with more larger value display and information 4) Embedded 25V capacitor table at LCD, auto display the capacitor is good or bad reference to common 25V electrolytic capacitor. 5) New plastic case, curve design for hand carrying. New stand for 60 degree stand on desk. 6) Use 2X AA battery, more convenience and longer battery life than 9V battery. 7) Support external USB power, using standard micro-USB port. Specification: Range Accuracy (After Zero, tested with 1,10,100R resistor) Refresh Time (Manual Mode) *Auto mode take 0 to 2s more time depend on value 0.000 to 1.000R 1%+2Digit ~0.4s 1.000 to 10.00R 1%+1Digit ~0.4s 10.00 to 100.0R 2%+1Digit ~0.4s *Accuracy maybe affected by the test lead’s length and contact point resistance. Standard test leads is 15cm, for longer test leads need special shielding to affect the EMI inference (Can contact sales’ person for more detail) 1) Accuracy: Up to 1% (detail on above table) Wide Measurement Range: >1uF (for 0.1uF the error will be larger on equation 1/(2*pi*F*C) @ 100Khz ) 2) High Resolution: 4 digit, or 0.001Ohm @ 1 Ohm range 3) Measuring voltage: <~40mV RMS (TESTING VOLTAGE) 4) Clamping voltage: ~0.15V (open voltage) 5) Battery 2X AA 1.5V battery 6) External Power: 5V micro USB 7) Operating current 0.02A 8) Battery Life time: >80 Hours Operating Introduction: 1) POWER ON Press and hold the ON/ OFF circle orange button for 2 to 3 second to power on. Press and release the ON/ OFF button to shut down meter. 2) AUTO/ MANUAL mode: i) Auto Range: Press and release the RANGE button and at the first line of LCD will show “AUTO:" At auto mode meter will automatically select the best range to detect. ii) Manual Range: Scroll the manual range from 1R, 10R and 100R range by press and release the RANGE button In LCD will show MANUAL at first LCD line and show at second line: 0-1R, 1-10R and 10-100R. 3) 1 Key Zero: Short circuit the test leads’ terminal, cancelling the wire resistance. Press and release the “ZERO" button, LCD shows “ZERO" and wait the zero disappear. If you are using the meter array socket, you need to use a short pin to short circuit to set zero. 4) Backlight: LCD backlight will on during power on 5) Auto Sleep: Around 10 hours for not testing, it will shut down automatically to save power. 6) OVERFLOW or OL: Display overflow when the value is out of range, you can check that you are zero correctly. 7) ESR TABLE: It is for reference only, different manufacturer of capacitor has different ESR, better to test a good cap ESR and compare with what you are testing, usually bad cap with higher ESR few times larger than good one. 8) SOFTWARE ESR: Put the 25V Electrolytic capacitor value to LCD, and compare, GOOD if C < XXuF, means the capacitor maybe good condition if it is less than XXuF 9) PLASTIC STAND: If you don’t use the stand, press and push the lock position: Package Content 1 unit MESR-100 V2 1 pair 15cm test clips (as photo) LCR M4070 AutoRanging LCR Meter Up to 100H 100mF 20MR Download Manual: http://www.mib-tech.com/product_manual.html M4070 LCR METER Special Features: M4070 LCR meter is auto-ranging component tester, can drive up to 500 KHz, suitable for small value capacitor and inductor measurement. It provides very stable and high resolution measurement up to 5 digits. Meter can measure 0.00pF to 100.00mF capacitance, 0.000uH to 100.00H and 0.00?? to 10.000M?This meter is using two technique measurement, LC oscillation and RC oscillation. LC is much suitable for small value measurement and RC for high value capacitance. *Discharge Capacitor before Testing!! Features: - Fully auto-ranging designed - High resolution, up to 5 digit display, most finest resolution: 0.01pF, 0.001uH, 0.01R - High stability and measurement range for L/ C/ R - USB charging with rechargeable battery inside - Large LCD display with backlight - USB PC program, can take record and pass and fail component sorting function. Measurement Photo: Specification:: Model: M4070 LCR Meter Series LCR Testing Parameter Main Parameter: L / C / R Testing frequency C: 10 to 500Khz L: 10 to 360Khz Testing Method Auto select LC and RC Oscillation Calibration Power on auto calibrate with internal reference capacitor Testing voltage ~1.5Vrms Best Tolerance L: 1% +1 Digit C: 1% +1 Digit R: 0.5% +1 Digit LCD update or Testing time (* vary on component value) <3/s, (e.g. 100mF Capacitor <30s) Range Selection Automatically Zeroing Open / short circuit Terminal Mini-USB(Virtual Com Port) Display Range C 0.00pF ~100.000mF (pF/nF/uF/mF) L 0.000uH ~ 100.000H (uH/mH/H) Hz (LC Oscillation Frequency)) 0 to 900000Hz (s) (RC Constant Time) 0.000 to 99.999 R 0.00 ? ~ 20.000 M? (?/k?) LCD Display 128X64 Dot Matrix, with backlight Fuse Protection 200mA Charging terminal Mini-USB (500mA) Battery internal 3.7V Li-polymer Number of Testing Terminal Main 3, Secondary 4 Reading Display Max. 99999 COMPARSION WITH OTHER LCR METER: Measurement Comparasion Capacitor (Marked Value)) TH2822A (10KHz) LC200A M4070 Reading Frequency Reading Frequency (Hz) % with TH2822A Absolute % Error Reading Frequency (Hz) % with TH2822A Absolute % Error 5pF 5.41 10Khz 5.06 654224 6.47 6.47 5.37 490920 0.74 0.74 33pF 31.54 10Khz 30.03 645310 4.79 4.79 31.29 485340 0.79 0.79 75pF 73.6 10Khz 71.42 634132 2.96 2.96 71.19 477160 3.27 3.27 330pF 341.33 10Khz 332.5 571000 2.59 2.59 333.25 431890 2.37 2.37 1000pF 949.7 10Khz 940.6 474000 0.96 0.96 946.37 361110 0.35 0.35 68nF 54.68 10Khz 54.7 107200 -0.04 0.04 56.614 61900 -3.54 3.54 10nF 11.473 10Khz 11.73 194900 -2.24 2.24 11.52 141520 -0.41 0.41 100nF 70.87 10Khz 68.38 102000 3.51 3.51 69.555 62700 1.86 1.86 1uF 1.0708 100Hz 1.05 1.94 1.94 1.0883 -1.63 1.63 33uF 33.286 100Hz 34.9 -4.85 4.85 34.735 -4.35 4.35 220uF 196.78 100Hz 205 -4.18 4.18 203.69 -3.51 3.51 470uF 448.7 100Hz 475 -5.86 5.86 468.04 -4.31 4.31 2.2mF 2.0203 100Hz 2.15 -6.42 6.42 2.1142 -4.65 4.65 22mF 19.408 Series 19.8 -2.02 2.02 20.04 -3.26 3.26 5pF to 100nF is small capacitor with ceramic . While 1uF to 22mF is Electrolytic Capacitor. Small Cap Standard Deviation % Compare with TH2822A 2.76 2.07 Large Cap Standard Deviation % Compare with TH2822A 3.10 1.11 Small Cap Average Abs Error % Compare with TH2822A 2.94 1.67 Large Cap Average Abs Error % Compare with TH2822A 4.21 3.62 Model of commom LCR meter DM4070 TH2822A LC200A M4070 Price (Loweset in Ebay @2012 Oct 16) 34.8USDD 213USD 35.98USD 59USD Testing Frequency 1kHz 100Hz,120Hz,1kHz,10kHz 500khz 10 to 500khz Capacitor 0.1 pF ~ 2000 uF 0.00pF ~20.000mF 0.00pF to 100.000mF 0.00pF to 100.000mF Inductor 0.1uH ~ 20H 0.00uH ~ 1000.0H 0.000uH to 100.000H 0.000uH to 100.000H Resistor 0.01R ~ 20MR 0.0000 ? ~ 10.000 M? NAA 0.00 to 10.000MR Minor measurement (Phase, %, D) No Yes No No Resolution 1999 40000 9999 99999 Capacitor Accuracy 2.50% 0.25% 1% 1% Inductor Accuracy 2.50% 0.25% 1% 1% Resistor Accuracy 0.50% 0.25% NA 0.50% Range Manual Select Fully Auto Semi Auto (need manual select large or small scale) Fully Auto Terminal & Socket 2X Test Lead, 2X Socket 2X Test Lead, 2X Socket 2X Test Lead 2X Test Lead, 2X Socket PC Program No Yes No Yes PC Terminal No USB No USB Zero Function No Yes Yes Yes Power 9V Battery 9V Battery /12V External Power 4XAA Battery /External 5V Power Li Polymer rechargeble / USB power Fuse Protection (Capacitor Measurement) Self Discharge No No Yes Low Battery Alarm Yes Yes Yes Yes Display Segment LCD Segment LCD Dual display reading 16X2 Character LCD 128X64 dot matrix LCD Backlight NO Yes Yes Yes INCLUDE: 1) 1 pcs M4070 2) USB Cable 3) Download labview software: http://www.mib-tech.com/product_manual.html MIB-INSTUMEN Paymentt Shipping We accept Paypal, credit card through Paypal. Buyer may need to pay for import tax depend on your country's custom. You can ask us for more detail. We ship from UK Store for this listing If buyer not at UK or Europe, we may ship from HK Items are shipped within 2-3 business day after receive cleared payment. An additional USD2 for insurance Most item will arrive within 8-14 business days. It depend on your location. In some case, ship to some countries will take over 3 weeks, especially brazil, Italy and France . On Aug-12-14 at 02:42:09 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	MIB
Country of Manufacture	China
Model	M4070+ESR100
