Chroma 63600-5 Main Frame W 2pcs Dual Ch 63610-80-20 Plugins Electronic Loads

US $2,550.00

Howell, Michigan, United States
Jun 9th

Open on mobile:
QR code

For sale is one USED in good condition and good operating Chroma 63600-5 5 bay Main Frame and two 63610-80-20 dual cahnnel electronic load plugins Works as expected Includes everything shown only! No software Included main frame, 2 dual hannel plugins, 4 high current cables, 4 sense leads and tightening tool for banana jacks Unit is HEAVY, it will be shipped in two large boxes, Main frame in one box, Plugins in the other box. Shipping cost showh are for the the USA lower 48 only! SOLD AS IS NO WARRANTY NO RETURN! Some information from the internet on both items: Description Chroma’s 63600 Modular DC Electronic Loads are designed for testing multi-output AC/DC power supplies, DC/DC converters, chargers, batteries, adapters, and power electronic components. They are excellent for research, development, production, and incoming inspection applications. The 63600’s state of the art design uses DSP technology to simulate non-linear loads using an unique CZ operation mode allowing realistic loading behavior. The 63600 series can draw its rated current under very low voltage (0.4V typical). This unique feature guarantees the best loading performance for modern Point-of-Load conditions and fuel cells. Real time measurement of voltage and current are integrated into each 63600 load module using a 16-bit measurement circuit with three current ranges. The user can perform online voltage measurements and adjustments or simulate short circuit test using the simple keypad on the front panel. With the VFD display and rotary knob, the 63600 loads offer versatile front panel operation. Users are able to control the 63600 family remotely via Ethernet, USB, or GPIB interface. Also included in the 63600 are self-diagnostic routines and full protections against OP, OC, OT and alarm indicating OV, reverse polarity. This ensures the quality and reliability of the 63600 and provides protection of units under test. Key Features · Max. Power : 100W x 2(Dual), 300W, 400W · Voltage Range : up to 80V · 5 module mainframe Max. 2000W, load modules up to 400W/ea · Up to 10 channels in one mainframe, fit for testing multiple output SMPS · 0.4V @ 80A (Typical) low voltage operating characteristics · Flexible CC, CR, CV and CP operation modes · CZ mode for turn on capacitive load simulation (up to 50,000uF capacitance emulation) · Parallel mode for high current and power application up to 2kW · Multi Channel synchronous control · Real time power supply load transient response simulation and Vpk+/- measurement · User programmable 100 sequential front panel input status for user-friendly operating · Over current protection (OCP) testing function · Precision voltage and current measurement · Precision high speed digitizing measurement/ data capture · Voltage, Current and Pmax measurement for OCP/OLP testing · Timing measurement for batteries · Short circuit simulation · Self-test at power-on · Full Protection : OC, OP, OT protection and OV alarm · Ethernet, USB and GPIB interfaces · User Defined Waveforms Chroma's 63600 Series DC Electronic Loads are designed for testing multi-output AC/DC power supplies, DC/DC converters, chargers, batteries, adapters, and power electronic components. Excellent for research, development, production, and incoming inspection applications. The 63600's state of the art design uses DSP technology to simulate non-linear loads using an unique CZ operation mode allowing realistic loading behavior. The 63600 series can draw its full rated current to almost zero volts. This unique feature guarantees the best loading performance for fuel cells and modern Point-of-Load devices. · Chroma 63610-80-20 Features: o Three Current Ranges Per Load o Max. Power: 100W x 2(Dual) o 80V o 20A o Derated Current to 10mV o Constant Impedance Mode o USB, GBIP, Ethernet o Digitized Volt & Current Readback (2µs sampling) Features and Specifications of the Chroma 63610-80-20 DC Load Module include: Three Current Ranges Per Load Derated Current to 10mV Constant Impedance Mode USB, GBIP, Ethernet Digitized Volt & Current Readback (2µs sampling) 100 Programmable Loading Sequences that enable the user to simulate various real world conditions Model: Configuration: 100Wx2 Voltage: 0~80V Current: 0~0.2A 0~2A 0~20A Power: 16W / 30W / 100W Static Mode: Typical Min Operating Voltage (DC): 0.5V@0.2A 0.5V@2A 0.5V@20A Constant Current Mode: Range: 0~0.2A 0~2A 0~20A Resolution: 0.01mA 0.1mA 1mA Accuracy: 0.1%+0.1%F.S. Constant Resistance Mode: Range: CRL : 0.04~80 ohm (100W/6V) CRM: 1.44~2.9k ohm (100W/16V) CRH : 5.76~12k ohm (100W/80V) Resolution: 0.3288m mho Accuracy: 0.1%+0.075 mho (6V) 0.1%+0.01 mho (16V) 0.1%+0.00375 mho (80V) Constant Voltage Mode: Range: 6V / 16V / 80V Resolution: 14 bits Accuracy: 0.05%+0.1%F.S. Constant Power Mode: Range: 2W / 10W / 100W Resolution: 1mW / 10mW / 100mW Accuracy: 0.3%+0.3%F.S. Dynamic Mode - CC Min Operating Voltage: 1.5V Frequency: 100Hz~50kHz / 0.01Hz~1kHz Duty: 1~99% (Min. Rise Time Dominated) Accuracy: 1µs / 1ms+100ppm Slew Rate: 0.04A/ms~0.02A/µs 0.4A/ms~0.2A/µs 4A/ms~2A/µs Resolution: 9 bits Min Rise Time: 10 µs Current: Range: 0~0.2A 0~2A 0~20A Resolution: 14 bits Ext Wave Mode(20KHz): CC: Range: 0~0.2A 0~2A 0~20A Level: 0~10V Accuracy: 0.5%F.S. Program Mode: Sequence No: 100/Program Dwell / SEQ: 0.1ms ~ 30s (Resolution : 0.1ms) Load Setting: Refer to Static mode specifications Spec Check: Voltage / Current / Power Measurement: Voltage Read Back: Range: 6V / 16V / 80V Resolution: 0.1069mV 0.2489mV 1.3537mV Accuracy: 0.025%+0.01%F.S. Current Read Back: Range: 0~0.2A 0~2A 0~20A Resolution: 0.003349mA 0.034628mA 0.329561mA Accuracy: 0.05%+0.05%F.S. Power Read Back: Range: 2W / 10W / 100W Accuracy: 0.1%+0.1%F.S. Voltage Monitor: Bandwidth: 20 kHz Range: 6V / 16V / 80V Output: 0~10V Accuracy: 0.5%F.S. Current Monitor: Bandwidth: 20 kHz Range: 0~0.2A 0~2A 0~20A Output: 0~10V Accuracy: 0.5%F.S. PAYMENT—SHIPPING—RETURN STATEMENTS BASICS: I have no way to verify all functions. Any deficiencies known will be listed! Pictures are of actual item(s) for sale. PAYMENT: I accept Pay Pal (PayPal Preferred), Payment to be received within 3 days after auction ends! SHIPPING: If you are A NON USA buyer, Please be aware that Ebay has changed the shipping invoice procedure, The buyer must complete the Invoice! (the check out). When using the Ebay Global Shipping. I normally ship on Tuesday and Thursday!! I only ship by methods that provide tracking!! If “Free Shipping “ is listed it applies to the USA Lower 48 states only! All others will need to be quoted! @@ Please keep in mind, I due refund shipping overages!! As the Ebay calculator is sometimes wrong. Especially on large packages!!! I Do Not Ship to P.O. Boxes!! I only ship to Real addresses that are Paypal verified. INTERNATIONAL CUSTOMERS: NO MEANS TO TEST, and due to the cost to ship internationally and the distance items have to travel, ALL items shipped outside of the USA are SOLD AS IS WITH NO GUARANTEES. All sales are final. No refunds or returns, please bid accordingly! EMAILS: I check emails regularly Monday thru Friday, Emails on the weekend may not occur depending on my schedule. So please be patient. As you might have to wait till Monday for an answer!! RETURNS: If an item can be returned (see auction description), It must be in the same (original) condition that it was shipped in. Any tampering or breakage (not due to shipping accident) voids any return policy! Item will also be shipped back by original shipping method and packing!! Return shipping is paid at the expense of the buyer! Good Luck. Thank you for looking and or bidding

“Includes main frame , 2 dual channel plugins, cables and tightening toolWorks as expected”
