Fluke 43b Power Quality Analyzer

US $2,199.00

Constanta,Constanta, Romania
Jun 9th

Open on mobile:
QR code

Specifications Input characteristics Input impedance 1 M?, 20 pF Voltage rating 600 V rms, CAT III V/A/Hz display True-rms voltage (AC + DC) Ranges 5.000 V, 50.00 V, 500.0 V, 1250 V1 Accuracy ±(1% + 10 counts) True-rms current (AC + DC) Ranges 50.00 A, 500.0 A, 5.000 kA, 50.00 kA, 1250 kA Accuracy ±(1% + 10 counts) Frequency Ranges 10.0 to 15.0 kHz Accuracy ± ([% of reading] + [counts]): 0.5% + 2 CF crest factor Ranges 1.0 - 10.0 Accuracy ±(5% + 1 count) Power display Watts, VA, VAR 1-phase and 3-phase,3 conductor balanced loads Ranges 250 W - 1.56 GW Accuracy ±(4% + 4 counts) Fundamental Power Accuracy ± (2% + 6 counts) Total Power PF power factor Range 0 - 1.0 Accuracy ±0.04 DPF displacement power factor, Cos .F Range 0.25 - 0.9 Accuracy ±0.04 Range 0.90 - 1.0 Accuracy ±0.03 H2 frequency fundamental Ranges 40.0 to 70.0 Hz Accuracy ± ([% of reading] + [counts]): 0.5% + 2 Harmonics display Voltage, current, frequency Ranges Fundamental to 51st harmonic Accuracy VA ±(3% + 2 counts) W ±(5% + 2 counts) Fundamental 2 to 31st harmonic VA ±(5% +3 counts) W ±(10% +10 counts) 32 to 51st harmonic VA ±(15% +5 counts) W ±(30% +5 counts) Frequency fundamental Ranges 40 Hz to 70 Hz Accuracy ±0.25 Hz Phase Range V, A (Between fundamental and harmonics) Accuracy ±3° to ±15° Range W (Between voltage fundamental and current harmonics) Accuracy ±5° to ±15° K-factor (Current and Power) Range 1.0 to 30.0 Accuracy ±10% THD total harmonic distortion Range 0.00 - 99.99 Accuracy ±(3% + 8 counts) Sags and swells Recording times 4 min to 16 days (selectable) Vrms actual, vrms max, min (AC + DC) Ranges 5.000 V, 50.00 V, 500.0 V, 1250 V1 Accuracy Readings ±(2% +10 counts); Cursor readings ± (2% + 12 counts) Arms actual, arms max, min (AC + DC) Ranges 50.00 A, 500.0 A, 5.000 kA, 50.00 kA Accuracy ±(2% +10 counts) Transient capture Minimum pulse width 40 ns Useful bandwidth input 1 DC to 1 MHz Number of transients 40 Voltage threshold settings 20%, 50%, 100%, 200% above or below reference Reference signal After START, the Vrms and frequency of the signal are measured. From these data a pure sinewave is calculated as reference for threshold setting. Vpeak min, vpeak max at cursor 10 V, 25 V, 50 V, 125 V, 250 V, 500 V, 1250 V Accuracy: ±5% of full scale R, C, diode, continuity Resistance ranges 500.0 ?, 5.000 k?, 50.00 k?, 500.0 k?, 5.000 M?, 30.00 M? Resistance accuracy ±(0.6% + 5 counts) Capacitance ranges 50.00 nF, 500.0 nF, 5.000 µF, 50.00 µF, 500.0 µF Capacitance accuracy ±(2% + 10 counts) Diode Ranges 0 to 3.000 V Diode voltage Accuracy ±(2% + 5 counts) Continuity Beeper on at < 30 ? ± 5 ? Max current 0.5 mA Temperature °C or °F Inrush current Inrush times 1 s, 5 s, 10 s, 50 s, 100 s, 5 min Current ranges 1 A, 5 A, 10 A, 50 A, 100 A, 500 A, 1000 A Cursor readings A peak max at cursor 1 and cursor 2 Accuracy ±5% of full scale Time between cursors 4 to 235 pixels (1 pixel = inrush time/250) Accuracy: ±(0.2% + 2 pixels) Temperature (with accessory) Range -100 °C - 400 °C Accuracy ±(0.5% + 5 counts) Scope display Measurements DC, AC, AC + DC, peak, peak-peak, frequency, duty cycle, phase, pulse width, crest factor Time ranges 20 ns/div to 60 s/div Max sampling rate 25 MS/s Bandwidth Voltage channel [1] 20 MHz at inputs, 1 MHz with TL24 leads Current channel [2] DC to 15 kHz at inputs, 10 kHz with i400s current clamp Coupling AC, DC (10 Hz - 3 dB) Vertical sensitivity 5 mV/div to 500V/div Vertical resolution 8 bit (256 levels) Record length 512 samples per channel Base ranges 60 S/div to 20 nS/div ± (0.4% + 1 pixel) Timebase modes Normal, roll, single Pre-trigger Up to 10 divisions Trigger Source Input 1 or input 2 or automatic selection Trigger Mode Automatic Connect-and-View™, free Run, and single Shot Connect-and-view™ Advanced automatic triggering that recognizes signal patterns Automatically adjusts triggering, timebase and amplitude and displays stable pictures Memories 20 (screens, settings, data) Recording Recording times 4 min to 16 days (selectable) Parameters Choose one or two parameters from one of the groups below Volts/Amperes/Hertz Power Watts, VA, VAR, PF, DPF, frequency Harmonics, THD, volts (Fund. and harmonic), amperes (F&H) watts(F&H) Frequency (H), %(H) of total, Phase(H), KF Temperature Resistance Resistance, diode, continuity, capacitance Scope DC voltage, DC current, AC voltage, AC current, frequency, Pulse width + or -, phase, duty cycle + or -, peak max, peak min, peak min-max, crest factor Environmental specifications Operating temperature 0°C to +50°C Safety specifications Electrical safety EN 61010-1 CAT III, 600V. CSA listed Mechanical and general specifications Size 232 x 115 x 50 mm Weight 1.1 kg Warranty 3 years Battery life Rechargeable NiMH pack (charger included), 6.5 hrs extended operating time (continuous) Shock and vibration Mil 28800E, Type 3, Class III, Style B The charger is new but is sprayed with red paint on a side

“The item is new, opened for testing. It works perfectly, not used. It came with extra accessory, extra battery, it is sell with all items on the pictures.”

Brand	Fluke
Model	43B
