Cnc 3040 Usb 3axis Router Engraving Drill Mill Metal Carvings 3d Cutter Machine

US $6000

Basel, Switzerland
Jul 12th

Open on mobile:
QR code

Store category Sign Up Now ! You may also like CNC 3040 USB 3AXIS Router Engraving Drill Mill Metal Carvings 3D Cutter Machine Product Description Disadvantages of simple engraving machines on the market: 1. The drive board is small and can't work for a long time. 2. The drive can only use 42 small stepper motors with low torque. 3, the structure is simple, the stability in the machining process is not enough. 4, the structure is simple, the stability is not good, can only process some soft material materials, and there is no precision, about the screw drive system,it used the simple screw rod. 5, it's not suitable for advertising stores, woodworking, metal carvings and other shops for long-term use, because the equipment replacement cycle is short, long-term calculations, the cost will be higher. Thus, please note: choosing our heavy-duty engraving machine is a good way to avoid these disadvantages. Technical Parameters: 3040T triaxial engraving machine part parameters: Effective working travel: 275(X)mm*385(Y)mm*65(Z)mm Shape dimension: 610x480*400mm Max.workpiece dimension: 60mm Work table dimension: 320mm*530mm Frame materials: aluminum alloy 6063 and 6061 Lead screw: 1204 double thread Trapezoidal screws Driving units: X axis 1204 trapezoidal screws Y axis 1204 trapezoidal screws Z axis 1204 trapezoidal screws Sliding units: X axis Dia.16mm chrome plate shafts Y axis Dia.16mm chrome plate shafts Z axis Dia.12mm chrome plate shafts Stepping motor type: 57 two-phase 1.8A Spindle motor: 400w dc motor 500~8000PRM/Min Principal axis collet: ER11 / 3.175 mm Repeat accuracy: 0.05mm Spindle precision: radial beat acuities 0.03 mm Control unit: triaxial one-piece drive + ring variable power + PWM speed Carving Instructions: G-code/.tab /.nc / .ncc/.txt Communication interface: through USB connection with computer Software environment: Windows 7 / xp Maximum Idle speed:0-1500mm/min Working Speed :50-1500mm / min (different material with different speed settings) Machine weight: 28KG Control box parameters: Operating Voltage: AC220V Control unit: 2.5A stepping motor driver plus adjustable spindle speed controller Computer connection: USB Command code: G code Protection: Emergency stop button Instalation tips The software perferm better on the 32bites system computer. Please close the firewall and antivirus software on the computer before DOWNLOAD AND install the software.(This is very important) Otherwise, the antivirus will regards the cnc software is virus and stop the installation. PS: Please don't update the software when installed, then it will not need the license Numbers. More Precise Stepping Motor The engraving process is visible as controlled by computer Simple operation and installation Engrave almost anything on almost any surface XYZ axis carving make more precise and and three-dimensional effect Cover plates reducing pollution for the screws and shafts. More steady and strong equiped with aluminum alloy frame materials Reinforced and thickened machine body make transportation absolutely to be safer and longer life time 2 year machine part Free Warranty Introduction: CNC3040 is suitble for Industry,Technology Research,Advertising Design,Arts Creation,Teaching, Student Project and Hobby Purposes. CNC3040 is a desktop CNC machine and designd for processing Industrial or Hobby Prototype Building, Building Model Making,PCB,Adverstising Signs,Artwork,Crafts,Aircraft Models,RC Model parts,etc.So,you can do engraving work at office or home. Exquisite 3040 is a miniature version of mobile longmen structure of carving machine, put on you computer is like puting a printer or scanner that coordination,and can completely as a compute peripherals tools, anywhere,anytime,help you to design intent fast real appear.Nonmetal materials on the milling,and it can also be used to carving simple PCB/CNC. Application: This 3040 engraer is a user-friendly desktop engraving machine for those with limited space and /or a limited budget. The Computerized CNC Engraving and Cutting Machine is suitable for various materials, such as WOOD, PMMA or other plastic, MDF board,native wood,PVC,Acrylic, wood,composite board plywood,It can be used widely to process or make adverstising signs,PCB,nameplates,badges,seals,bronzing plate,aluminium alloy,acryplates, ABS resin double color plate,PVC foaming board,indentation plates,signs,construction models,instrument panels,wooden products,etc. If you want to make sure this engraver will engrave on a certain item or cut a certain item, you are welcome to send me a sample of that item and I will test it for you. Feature: 1 year machine part Free warranty Simple operation and installation More steady and strong equiped with aluminum alloy frame materials Can be controlled by computer Can control the engraving more precise Emergency stop button enhance security Large 3D engraving in soft wood,MDF board,native wood,PVC,Acrylic we suggest use one or two spiral flute ball bits. Can engraving much more materails by spiral flute bits,such as metal,steel,MDF board,solid wood Payment Delivery details Return policy Feedback Con-tact us Payment We accept PayPal payment only Payment must be received within 7 days after order is made. Fees such as import duties, taxes are not included in the item price or shipping costs. These charges are the buyer's responsibility. Delivery details Please pay attention to the payment in advance: according to experience, a transfer takes 2-3 days depending on the bank until the money is over. As soon as your payment is received, we will send you the goods within 48 hours. On Saturday and Sunday there is no delivery and no shipping. Please note: We ship parcels from Germany warehouse to europe buyers! 3-7 days: GERMANY 5-10days: Other countries We promise that every item has been sent. But sometimes there is also 0.3% package lost during transport . If this happens after we have confirmed this with the post, we will send you the package again as soon as possible or refund the money immediately. Return policy Your satisfaction is our ultimate goal. We work hard to earn your trust and future business. Our certified technicians have tested each item before shipping. The unit comes with 1 year limited warranty on all manufacturing defects. a) If you receive a defective item, Please tell us the problem in details and Please con-tact us within 14 days after you receive the package. b) What you returned must be intact and in its original packaging as received . Customer is responsible for shipping costs of the returned item caused by misorder,or don't need it anymore. c) We will cover the cost of shipping if the item is defect when you received. Or We will send you a new unit or refund the full payment you paid. Feedback Thanks for buying my business. If you have any problem with the item, if you have got it, please do not hesitate to contact us. We will provide you the best solution for any problem with the item. We would be delighted if you kindly contacted us before requesting a return or leave negative feedback. Con-tact us Business Hour : Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply you-= within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please con-tact us with ebay message. Please feel free to con-tact us if you have any questions. Feedback On Jul-12-21 at 02:14:10 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	shipping notice	Can not ship to Puerto Rico,Alaska/Hawaii
Principal axis collet	ER11 / 3.175 mm
Marke	Markenlos
Repeat accuracy	0.05mm
Herstellernummer	nicht zutreffend
Spindle precision	radial beat acuities 0.03 mm
Werkzeugart	Schaftfrser
Carving Instructions	G-code/.tab /.nc / .ncc/.txt
Effective working travel	275(X)mm385(Y)mm60(Z)mm
Communication interface	through parallel connection with computer
Shape dimension	610x480*400mm
Machine weight	28KG
Max.workpiece dimension	70mm
EAN	Nicht zutreffend
Work table dimension	320mm*530mm
Brand	Unbranded
Frame materials	aluminum alloy 6063 and 6061
MPN	Does Not Apply
Leadscrew	1204 double thread Trapezoidal screws
Control	CNC
Stepping motor type	57 two-phase 1.8A
Machine Type	3 Axis Router Machine
Spindle motor	400w motor 500~8000PRM/Min
UPC	Does not apply
