Cnc Milling Kit 220v Air Cooled 4.5kw Atc Spindle Motor Bt30 & 5.5kw Inverter

US $1,776.00

Shanghai, China
Aug 17th

Open on mobile:
QR code

Package include: 1 x 4.5KW ATC Air cooled spindle motor ( BT30,24000rpm,4 bearings,800Hz, 220V ) 1 x BT300 Tool holder 1 x FuLing Brand 5.5KW 220V Inverter VFD 1 x Aviation plug Note: We also have 380V,if you need,pls contact us before purchase.Default is 220V. 380V style has stock in EU warehouse, 220V style has stock in US warehouse. English manual will be sent via E-mail,pls leave ur e-mail ID after purchase, thank u. 100% Brand New and High Quality!!! Product Description 4.5kw air-cooled automatic tool change spindle is a high-end woodworking company designed to develop high-power electric spindle bearings imported fom Germany, high-precision bearings, high precision, long life. The electric spindle fan cooling with Road gas seal structure, automatic tool changer with ISO30 shank, feast automatic tool change and improve the efficiency of the automated processing. Procuct Name 4.5KW air-cooled ATC spindle Power 4.5KW Voltage 380V(220V also in stock) Torque 3.6 Nm (Torque peaked at 12000 rpm) Speed 12000~24000rpm/min Frequency 800Hz Current 8A Collet ISO30 Pole number 4 Cooling Type air cooling Barometric pressure 6 bar Fixed way Two side,screw fixed Number of phases 3 Bearing 2*7008 2*7006 Warranty 1 year Packing list 1pcs spindle The usages of the product and warnings Matters need attention when you install this spindle 1. When installed, please carefully, pay attention to personal safety and to avoid injuries occurred during the installed process; 2. Do not use any tools tapping spindle; 3. Do not use sandpaper and grinding wheel to wipe or grind in axis core and taper hole; 4. Use special removal tool to remov the lock nut and the tool; 5. Untrained personnel can not disassemble and operate electric spindle; Attention to maintenance and maintenance 1. Electric spindle storage temperature is 20 ± 10 , humidity 85%, to allow time to store up to three months; 2. Electric spindle most suitable ambient temperature is 20 ± 10 , bearing life can achieve the desired optimum value; 3. The power cord must take waterproof measure, electric spindle housing must be grounded; 4. Electro-spindle must not exceed nameplate parameters;. 5. Not allowed to use any mechanical way to forced braking in the shaft; 6. after using the spindle every day,you should wipe spindle taper,then smear with rust oil; 7. Workplace must be clean, there should be strict dust control measures to prevent foreign matter enter the spindle. Product common malfunctions&method of exclusion Fault phenomenon Reason Method of exclusion Electric spindle is not running after boot 1No inverter power output or set incorrectly Check that VFD supply three-phase output voltage and setting method 2Spindle plug is not inserted Check the electrical spindle plug and connection. 3Bad plug connector 4Bad stator line package Replace line package Shutdown after a few seconds of the boot 1Start time i too short Increase the acceleration time 2Electric spindle high temperature cause line package insulation damaged Replace line package 3Electric spindle lose phase to run,then cause overcurrent protection blackout Check the electric spindle connection Electric spindle smoking or the housing hot after a few second of the boot 1Inverter output voltage, frequency are not match the use of electric spindle voltage and frequency Check the VFD and the spindle voltage, frequency 2The VFD is not set correctly Reset the VFD Locking nut loose when it is started Wrong direction of rotation Change the direction of rotation Spindle have big noise and vibration 1Bearing wear seriously Replace the bearing 2Precision of parts damaged,it’s effect dynamic balance Calibration of dynamic balance 3Big beat of Spindle Replace the spindle Locking nut loose when it is stoped Stop time is too short Increase the deceleration time Shipping Please open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediately We ship to worldwidebut If your country’s custom is strict, please contact us before you bid to check detail and confirmed. Delievry time USA post service round 10-18 business days Canada China post round 25-40 business days Australia China post round 20-35 business days Western EU(Germany,UK,France, etc) China post 20-35 business days Asia,South America,other countries Chins post round 15-40 business days Note:above offer is default delivery way,if you need fast delivery like as DHL/UPS or post service pls inform us to confirm the shipping cost before you bid Above DHL/UPS offer is without remote fee,if your post code is remote it need extra cost. All items will be shipped within 1-3 business days upon receipt of payment Payment We accept paypal payment,all Paypal must be confirmed(shipping and billing address must match and correct and it need tell us your telephone no for delivery) Payment must be made within 48hours of the auction end time Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Problem&Feedback Please give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it. We are a new member in ebay now,and need understand both of sides Pls email us before you want to leave any negative feedback Refund When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos,after confirm we will refund your money,but the delivery charge paid by buyer. Contact us Welcome worldwide customer inquire and questions,we will try to do our best to feedback customer’s email within 1-2 business days,if not pls check the mail box again Customer’s satisfaction is very important to us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Non-Domestic Product	No
Bearing	4pcs 27008 27006 bearing
Modified Item	No
Pole number	4
Country/Region of Manufacture	China
Voltage	220V OR 380V
Custom Bundle	No
Frequency	800Hz
Item Type	4.5KW ATC
Power	4.5KW
Torque	3.6 Nm (Torque peaked at 12000 rpm)
MPN	Does not apply
Model	4.5KW air-cooled ATC spindle
Inverter VFD	Fuling Brand 5.5KW
Cooling	Air cooled
Brand	RATTM MOTOR
Operating Speed	12000~24000rpm/min
UPC	Does not apply
