Cnc Router Machine R8 Spindle Automatic Tool Changer With Auto Probe

US $5,550.00

  • Hamtramck, Michigan, United States
  • Jan 30th
New Cnc Router Machine Automatic Tool Changer with Auto Probe  limit switch  if you need other dimension of machines  please contact us Ready  To  Go 4 x High-precision ball screw Q16mm pitch 5mm (C7) Guide Linear BearingV block Each axis of our machines has 4 V bearing blocks For Y X and Z 25mm Diameter Shaft Aluminum parts Mic 6 Precision Machined Cast Aluminum Plate Thickness 1/2 inches and 3/4 inches SPINDLE  R8   1100w brushless motor 6000rpm  Voltage: 115V or 220V Water pump for spindle NO CNC Driver Controller   4  x DIGITAL DRIVER    2  x POWER SUPPLY 350W - 36V 7.3A   4  x DB9 CABLE   1  x  DB 25 CABLE 4 x Stepper Motor 381 oz In. Hybrid Motor 1.8° /200 Steps Per Rev. 3.0 Amps Current Per Phase 4-wire Bi-polar Software  Mach3 Macro for setup tool chnger Software Demo Licensed Mach3 Rhino 4.0 Rhino cam 2.0 for g- code Dimensions  (L x W x H) 47" x 33" x 22" Work area dimensions Z-axis travel 170mm X-axis travel 420mm Y-axis travel 820mm Speed 40000mm/minute We need up to 20  days to send machine to you 260 pounds " 130kg " Shipping Our machine comes in 3 packages because it is fully put together. 1st package contains full assembly Y axis gentry 2nd contains X and Z axis fully assembled 3rd package contains CNC Driver, Stepper motor, Spindle        Tel 519-996-2519 Table cell To see more Cnc router videos click here Our Cnc Router cutting steel
