Cnc Warehouse Cnc Router/engraver/3d Carver Model Cm-1325-b

US $15,995.00

Houston, Texas, United States
Mar 9th

Open on mobile:
QR code

CM-1325B-400-0-000-1 Standard features: 1. Whole machine is welded with steel tube. 2. The machine uses gantry movement 3. Three axes uses Taiwan Hiwin high precision square guide rails; X and Y axes uses rack and pinion transmission, fast working,high efficiency and low cost. Z axis uses German-made ball screw, for high precision and long life. 4. Compatible with: CAD/CAM designing software e.g. Vectric Aspire/Type 3/Artcam/Castmate/Wentai etc. 5. Has the function of re-carving after break point and power failure. 6. Software can forecast processing time. 7. Uses advanced DSP system with USB connection, operated with the handle Eliminates need for a separate computer and issues with Microsoft versions. 8. Oil-injection system makes maintenance much easier. 9. Includes dust collector 10. Includes water pump and reservoir for spindle Applicable Industries: Wood processing: processing of various furniture such as door, window, cabinet, craft wood door, screen and so on. Advertisement: engraving and cutting various labels and number plate. Art craft: engraving characters of any languages and graphics on gifts and souvenirs. Applicable Materials: Wood, aluminum board, plastic, density board, MDF board, wave board, PVC, acrylic,crystal, light marble and other nonmetal materials and light metal materials. CNC Warehouse Model # CM-1325B Working Area (X*Y*Z) 49" X 97" X 7.75" Processing accuracy 0.01mm Repositioning accuracy 0.05mm Spindle 3.0KW variable speed , water-cooled Spindle rotating speed 0-24000rpm/min Max Moving Speed 984 ft/min Machine Structure Cast Iron Gantry, Welded steel Driving mode x,y Rack & Pinion Z Germany rolling ball screw, Hiwin square guide rails Voltage AC240V/60Hz/3ph Max. Power consumption 3.9KW Feeding Height 7.87" Drive motor Stepper Command G.code , mmg , plt , uoo,HPGL Compatible Software Vectric Vcarve/Aspire, Type3, Artcut, ArtCAM, masterCAM software Certificate CE,FDA Pack dimensions 67" X 114" X 65" wooden trunk Net weight 2,866 lbs Option: Rotary axis, vacuum table,dust collector,or bigger spindle .

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	CNC Router Engraver
Country/Region of Manufacture	China
Model	CM-1325-B
Country of Manufacture	China
MPN	CM-1325-B
