Complete Blow Mold Bottle Line

US $23000

  • Bucyrus, Ohio, United States
  • May 26th
Open on mobile:
QR code
TOYO MODEL BMSR-VP-1400 X 260HD 6-LAYER EXTRUSION, 18-STATION ROTARY WHEEL CONTINUOUS AUTOMATIC BOTTLE BLOW MOLDER. CONTROLS: HUNKAR 311 SERIES MODULE PROGRAMMER. VOLTAGE: MOTORS, 480 V; HEATERS, 220V; CONTROL, 110V. CAPACITY: 100 BPM (MAX). BODY LONG DIAMETER: 100MM; BODY SHORT DIAMETER: 80MM. TOTAL HEIGHT: 173MM (MAX). MOUNTABLE BLOW MOLD DIMS: LENGTH, 236MM; WIDTH, 168MM; THICKNESS: 68MM. NUMBER OF CAVITIES: 18; NUMBER OF TAKE-OUT ARMS: 6; NUMBER OF EXTRUDERS: 6 MS90-22, 90MM SCREW; L/D=22, MAXIMUM SPEED: 90 RPM. OUTPUT: 120KG PER HOUR. RESIN: PE MS40-25, 40MM SCREW; L/D=25, MAXIMUM SPEED: 60 RPM, OUTPUT: 10KG PER HOUR, RESIN: PEMS40-25, 40MM SCREW; L/D=25, MAX SCREW SPEED: 120 RPM, OUTPUT: 15KG PER HOUR. RESIN: ADHESIVE MS50-25, 50MM SCREW; L/D=25, MAX SCREW SPEED: 90 RPM, OUTPUT: 30 KG PER HOUR, RESIN: PE MS50-25, 50MM SCREW; L/D=25, MAX SCREW SPEED: 90RPM, OUTPUT: 30KG PER HOUR, RESIN: PE MS40-25, 40MM SCREW; L/D=25, MAX SCREW SPEED: 60 RPM, OUTPUT: 10KG PER HOUR, RESIN: EVOH MULTI-LAYER DIE HEAD WITH ORIFICE TOOLING AND PARISON PROGRAMMING M-8P-90 ROTARY REAMING MACHINE TO CONVERT BOTTLES INTO LAMACON TUBES WITH TUBE NECK REAMING ALL EXTRUDERS. MOUNTED ON COMMON MOTORIZED BASE, DRYERS AND HOPPERS. COMPLETE LINE WITH DETAILED SPECS, MANUALS AND DRAWINGS. MANUFACTURED 1993. EXCELLENT CONDITION.   This is a complete bottling line that was running when purchased.  Other equipment includes Moss 1050  5 color screen printing machine with a Kosme labeling head SN 4150 Kammann K 14 K 4 color screen printer with a Collomat 9130 label head SN 10047 Kammann K 14 K 4 color screen printer with a Collomat 9130 label head SN 10048 Moss Pin chain conveyor SN 4149 KC automation tray packer (2) SWF carton erector High speed label splicers misc hoppers conveyors etc.
