Complete Dry Type Transformer Temperature Monitoring, Control, & Cooling System

US $660.00

North Lewisburg, Ohio, United States
Jan 29th

Open on mobile:
QR code

Complete Dry Type Transformer Temperature Monitoring, Control, & Cooling System Transformer Temperature Monitoring and Control System TEMPERATURE MONITORING & CONTROL OF MV DRY TYPE AND CAST RESIN TRANSFORMERS LIST PRICE FOR ALL COMPONENTS NEW IS $2,500+ Removed from 1500kVA 3-phase transformer manufactured in 2006 All components operational when removed. Note: Bars that fans are mounted shown in picture will not be shipped with this package. Package includes TECSYSTEM T2612-B Temperature Monitoring Unit w/ flush mount cabinet & Instruction Manual, (3) TECSYSTEM PTSE-2.5 Temperature Sensors, (12) FASCO D558 motors w/ 7" fan blades, and wiring shown in pictures. Temperature monitoring unit is for cast resin or dry type transformers. The T-2612 is a state of the art temperature controller that utilizes the most advanced technology available. The T-2612 features a large front panel display along with large 3 digit temperature display. It is ideal for up to 4 thermal alarm channels for the temperature control of resin and dry-type transformers. The T2612-B is a combo unit to control the temperature of MV dry type and cast resin transformers and the power of the fan cooling system. It is recommended in combination with high-powered cooling systems, as it has two FAN outputs with maximum capacity of 16 Amp which can also be activated manually. The metal structure is designed for installation on the front door of a Panel or of the metal box of the transformer. 4 Pt100 inputs allow the reading of the temperature of the 3 windings and possibly of the core or the ambient. The unit is equipped with dry contacts to signal FAULT, ALARM and TRIP. For the fan control the unit has 2 active outputs which provide power directly to the fan motors. The unit is certified for the American and Canadian markets. MAIN SPECIFICATIONS 3 or 4 inputs from Pt100 3 wires 2 alarm levels equal for all the inputs Alarm for FAULT sensors Alarm contact rating: 5 Amps. 250 VAC res. Two separate cooling level with fan contact ratio or 16 Amp (220 VAC res.) AUTO-MAN cooling fan operation Buzzer for acoustic alarm signal. POWER SUPPLY: 120 or 240 Vac 50/60 Hz T-2612 Features • 4 inputs; utilizing Pt100 (RTD) 3 wire • Large Housing; 12.5" (H) x 6.25" (W) x 3.0" (D) • Large 3 digit display; 20.5mm • Trip, Alarm, Fault relay output • Audible Alarm Indication with mute button • 2 Fan Outputs; 10 amps each, fuse protected • Damaged RTD indication • Select from automatic channel scan, hottest channel scan or manual scan • Memory Recall feature; allows operator to review maximum temperature reached • Temperature monitoring from 0° - 200°C with large 20.5 mm display • Plug-in terminal boards Technical Specifications Power Supply • 120 - 240V AC selectable Inputs • 4 inputs Pt100 (RTD) - 3 wires • Removable rear terminals • Surge protection on all input channels • Sensor cable length up to 500 m Outputs • 3 alarm relays (alarm-trip-fault) • Contact rating; 5A - 250V AC res. • Fan 1 & 2 outputs protected by separate 10a slow fuses (max. 16a) • Output contacts capacity of fan relays: 20a-220Vac, 10a - 110Vac Tests/Performances • CE approved, cULu approved • Protection against electrical & magnetic noises • Accuracy: ± 1% full scale: ± 1 digit • Ambient operating temperature: -20°C to +60°C • Housing - painted steel panel; frontal part is IP 65 rated (waterproof) • Fan cycle test program Dimensions • 320 mm (12.5") x 210 mm (6.25") • Depth; 90 mm (with rear terminals) Displaying & Data Management • 1 display, 20.5 mm high w/3 digits for displaying temperature • 1 display for reference channel • LED indicating alarm or trip channel • LED indicating fault • LED indicating fan function • Temperature monitoring from 0°C to 240°C • Programmable to °F • Easily programmable with frontal push buttons • Select from automatic channel scan, hottest channel scan or manual scan • Alarm RESET push button on front panel • Maximum reached temperatures and alarm storage • Audible alarm buzzer List price for T2612-B (w/o Cabinet/Enclosure): $1,440 PTSE TEMPERATURE SENSOR Pt100 sensor Extension cable 3 wires with shield Standard cable length: 2,5 mt (different lenghts on request) TECHNICAL DETAILS Pick-up range: from -50°C to +220°C Protection: IP68 SENSOR Type: RTD Pt100 ohm at 0°C Coefficient ?=0,385 ? /°C Calibration: IEC 751, BS 1904 Accuracy: Class B CABLE Flexible tinned copper wires 3x22 AWG Primary insulation: silicon rubber Aluminium foil shield 100% Secondary insulation: blue silicone rubber Colour: 2 red conductors 1 white conductor TESTS Insulation test in ambient temperature (>5000 M ? with 2500 Vdc) Dielectric strength: 5KVac for 60" Model Number: PTSE - 2.5 Type Unit: RTD Pt100 Cable Type: 3 x 22 AWG Cable Length: 2.5 meters Sensor Diameter: 6mm (0) x 55mm Temperature Range: Max. 220°C List price for 3 sensors: $258.00 (12) FASCO D558 Motors w/ 7" Cooling Fan Blade Description: Designed for quiet, efficient fan duty operation Permanently lubricated Die-cast aluminum housing and end shield 2–9 watt 24" leads with molded strain relief or 2 watt, 25" leads on 4–9 watt Used with 7" to 10" hubless fan blades All have threaded shaft with hub Includes vibration dampener, hubwasher, speed nut and three mounting screws: 2 watt has four screws, 4 watt has three screws and 6–9 watt has five screws Agency Certification: UR/CSA; Ambient Operating Temp. (Celsius): 40; Bearing Type: Slv; Efficiency: 28.0%; Enclosure: TE; F/L Amps: 0.60; Hz: 60; Insulation Class: B; Mfg. #: D558; Mounting: All Angle; NEMA Frame: 51; Phase: Single; Rot.: CWOSE; RPM: 1550; Service Factor: 1.00; Speeds: 1; Thermal Protection: Impedance; Type: Shaded Pole; Volts: 115; Watts: 6 Product Specifications F/L Amps 0.60 Phase Single Type Shaded Pole Rot. CWOSE Efficiency 28.0% Enclosure TE Speeds 1 Bearing Type Slv Thermal Protection Impedance Mounting All Angle Insulation Class B Volts 115 RPM 1550 Watts 6 NEMA Frame 51 Service Factor 1.00 Hz 60 List Price for 12 Motors (w/o Fan Blade): $840

Condition:	Used: An item that has been used previously. The item may have some signs of cosmetic wear, but is fully operational and functions as intended. This item may be a floor model or store return that has been used. See the seller’s listing for full details and description of any imperfections. ...	Brand	TECSYSTEM Control & FASCO Fans
MPN	T2612-B, PTSE-2.5, & D558
Model	T2612-B, PTSE-2.5, & D558
