Content on this page requires a newer version of Adobe Flash Player. The Following Items Are Included: (2) Datacom Lancat V TwoWay Cable Testers (BC# 5749A 5749B) LANCat 5 Performance Module Calibration STD (2) Datacom Performance Modules P/N: 54456 (2) Datacom Performance Jack Modules RJ45 Adapter Jack (2) AC Adapter/Chargers RS232 PC Interface Cable User Manual On CD-ROM (2) Straps For Unit (2) Cases For Units Hard Carrying Case BE SURE TO CHECK OUR EBAY STORE FOR OTHER ITEMS! Datacom Technologies Textron LANcat V 100MHz Cat5 Test Set Test & Certify Cat5 Cabling Installations Includes Hard Carrying Case & Accessories As Listed Above! Working Condition: Excellent Condition: Refurbished Warranty: 90 Day Exchange Warranty High accuracy is needed to get reliable conformance certification of your new Category 5 LAN cabling installation. LANcat V is the only LAN field cable tester with the accuracy required to adequately test installed UTP and STP network links to Category 5 specifications. The TIA Link Performance Task Group TR-41.8.1 has identified signal imbalance and residual NEXT as primary contributors to NEXT measurement errors in "first generation" Category 5 cable testers. The LANcat V is the first portable cable tester designed expressly to minimize these error sources and to permit high confidence testing of Category 5 cabling. All the important functions that are needed to accurately test Category 5 wiring are included. Under Autotest, the LANcat V performs Wire Map, Near-End-Crosstalk (NEXT), Attenuation, Length, Resistance, Characteristic Impedance, and Attenuation-to-Crosstalk Ratio (ACR) tests for cable certification. Each test can also be run individually for diagnostic troubleshooting. Impedance Test detects up to three impedance discontinuities - useful for isolating cable damage. Under Quick CheckTM mode, an abbreviated test sequence of Wire Map, Length, NEXT and Attenuation is completed in less than 20 seconds for quick installation verification. All common cable types are supported. For the installer, service technician or LAN support specialist, the LANcat V is the one tester ideal for all types of LAN media or topology including UTP (Cat 3, 4, 5), STP, screened twisted pair, and coax. The LANcat V can store 500 test results for later printing or download to a PC. Each test record includes a time and date stamp plus a user assigned circuit ID name. The LANcat V was designed for maximum ease of use. The unique rotary function selector makes testing easy even for inexperienced users. A single remote unit allows fast, easy and accurate test setup. The large LCD display is backlighted to facilitate use in dimly lighted areas and Flash ROM permits easy firmware upgrades in the field. SPECIFICATIONS CABLE TESTS:The LANcat V certifies UTP and STP to EIA/TIA Standards. It also certifies coaxial, UTP and STP to IEEE and EC/ISO requirements. Tests performed include: Cable Length (via TDR) Wire Mapping Near End Crosstalk (NEXT) Attenuation Attenuation-to-Crosstalk Ratio (ACR) Resistance Impulse Noise Traffic (Ethernet Only) Characteristic Impedance LANCAT V CABLE TEST STANDARDS EIA / TIA-568 Cat 3 UTP EIA / TIA-568 Cat 4 UTP EIA / TIA-568 Cat 5 UTP 10BASE-T 4 16 Mbps Token Ring ISOIIEC 11801 Class CID 100BASE-TX 100BASE-T4 100BASE-VG ATM TP-PMD 10BASE-5 coax RG-58 coax 10BASE-2 coax RG-59 coax RG-62 coax CABLE LENGTH Range: 4000ft (1220m) Coax, 3000ft (915m) UTP & STP Accuracy: +\- 2ft (0.6m), 0-200ft (60m), +\- 1%, 201-4000ft (61-1220m) NVP (Nominal Velocity of Propagation): 0.50c to 0.99c, factory settings adjustable by the user. Cable Fault Types: Shorts, Opens, Intermediate Impedance Anomalies. Number Of Faults: End Of Cable and two Intermediate Anomalies. Fault Threshold. User defined, 4% to 10% (7% default). CALIBRATE NVP (Based on cable of known length) Minimum Length: 50ft Range: 0.50c to 0.99c WIRE MAPPING (Twisted Pair Wiring Only) Displays Following Errors: Miswired Pairs, Shorts, Opens, Shorted Pairs, Crossed Pairs and Split Pairs. Includes test of shield. NEAR-END-CROSSTALK (NEXT) (Tests all six pair combinations) Frequency Range: 0.77MHz to 10OMHz Measurement Range: 0 to -6OdB Accuracy: +/- 0.7dB ATTENUATION (Tests all four pair combinations one way) Frequency Range: 0.77MHz to 10OMHz Measurement Range: 0 to -6OdB Accuracy. +/- 0.7dB ATTENUATION-TO-CROSSTALK RATIO: ACR is calculated for each pair over the full frequency range per test specification selected. RESISTANCE: DC resistance of each conductor is measured. Range: 0 to 100OU Accuracy. +/- 1% IMPULSE NOISE: Counts impulse noise hits above user defined threshold. Threshold.- User defined, 1OOmV to 5OOmV peak (26OmV default) TRAFFIC (Ethernet Only) Parameters Monitored. % Utilization % Collisions Peak Traffic Other Features: Continuous bar graph to display activity. CHARACTERISTIC IMPEDANCE: (Measured for each pair using a TDR pulse.) Range: 40 to 180Q Accuracy: +/-10 Q NETWORK INTERFACE: Connectors: Standard: RJ45 male Options: RJ45 female, BNC coax or STP (IBM Type 1) SERIAL PORT Cable and Connector.- DB-9 Baud rate: 300 to 38,400 Protocol: Parity - Even, Odd, None Length: 8 Bits Flow Control: Hardware and Software POWER: Battery Standard: Eight AA Alkaline Batteries Option: Nickel Metal Hydride pack Battery Life: 8 hours typical use. Low Battery Indicator. Audible alarm plus LCD display. Automatic Power-down: 30 seconds to 10 minutes of inactivity (selectable). AC adapter: Supplied GENERAL Display. 128 x 64 pixel backlit graphic LCD Operating Controls: 10 position rotary function selector. Keypad: Elastomeric, dedicated functions, and 4 soft functions. Audible Alarm: Operator Enabled/Disabled TEST STORAGE Memory. Storage space for 500 test results. Imprint. Date and time on all tests Non-Volatile Memory. Lithium battery backed memory for setup, test results and NVP values. Please check our Huge Inventory with savings of up to 80% off of retail on Cat5/5e/6 LAN Cable Certifiers and Fiber Optic OTDR's, Fusion Splicers, CATV Meters, Fiber Optic Kits, Sources, Meters, Tools, Network Analyzers and much more. Here is a Link to our Ebay Test Equipment Store. All of our Test Equipment is backed with a Full Warranty and unbeatable customer support & service. Please don't hesitate to contact us for a Quote on Something you don't see in our inventory, sometimes we have items that may have not been listed or processed yet. Test Equipment Store Offers a wide range of Refurbished Telecom/ Datacom Tools and Test Measurement Equipment. Which includes Fiber Optic Test and Splicing tools, Fusion Splicers, OTDRs, Copper and Fiber Cable Certifiers, CATV Test Equipment, Cable and Antenna Analyzers, Network Analyzers and much more! We carry a large inventory of quality refurbished and used test equipment from all the major manufacturers. If you are looking for multiple quantities or if we don't have a listing for a particular item that you are looking for. Please contact us as it may be fresh inventory waiting to be listed or we'll be glad to find it for you at the best price possible and put up an eBay listing for you! Contact: Test Equipment Store eBay Sales Phone: 1-419-517-6681 Toll Free : 1-800-548-2381 We Ship World Wide! We will attempt to ship your item(s) within 24 hours after payment has been received. To get a real-time shipping quote to your destination, enter your country and zip / postal code information into the shipping calculator and click "Get Rate". Many countries impose their own customs, duties, tariffs, taxes, etc. on items being shipped from a foreign country. We do not cover those cost's and we recommend that you contact your countries customs agency for that information. We Offer Multiple Quantity Price & Shipping Discounts, Email Us If You Are Interested In Larger Quantities. Shipping Rate Calculator Enter your ZIP/POSTAL code: Select your COUNTRY: United States Canada United Kingdom Afghanistan Albania Algeria American Samoa Andorra Angola Anguilla Antigua and Barbuda Argentina Armenia Aruba Australia Austria Azerbaijan Republic Bahamas Bahrain Bangladesh Barbados Belarus Belgium Belize Benin Bermuda Bhutan Bolivia Bosnia and Herzegovina Botswana Brazil British Virgin Islands Brunei Darussalam Bulgaria Burkina Faso Burma (Myanmar) Burundi Cambodia Cameroon Cape Verde Cayman Islands Central African Republic Chad Chile China Christmas Island Cocos (Keeling) Islands Colombia Comoros Congo, Democratic Republic of the Congo, Republic of the Cook Islands Costa Rica Cote d Ivoire (Ivory Coast) Croatia, Democratic Republic of the Cuba Cyprus Czech Republic Denmark Djibouti Dominica Dominican Republic Ecuador Egypt El Salvador Equatorial Guinea Eritrea Estonia Ethiopia Falkland Islands (Islas Makvinas) Fiji Finland France French Guiana French Polynesia Gabon Republic Gambia Georgia Germany Ghana Gibraltar Greece Greenland Grenada Guadeloupe Guam Guatemala Guernsey Guinea Guinea-Bissau Guyana Haiti Honduras Hong Kong Hungary Iceland India Indonesia Iran Iraq Ireland Israel Italy Jamaica Japan Jersey Jordan Kazakhstan Kenya Kiribati Kuwait Kyrgyzstan Laos Latvia Lebanon Lesotho Liberia Libya Liechtenstein Lithuania Local State/Province Luxembourg Macau Macedonia Madagascar Malawi Malaysia Maldives Mali Malta Marshall Islands Martinique Mauritania Mauritius Mayotte Mexico Micronesia, Federated States of Moldova Monaco Mongolia Montenegro Montserrat Morocco Mozambique Namibia Nauru Nepal Netherlands Netherlands Antilles New Caledonia New Zealand Nicaragua Niger Nigeria Niue North Korea Norway Oman Other Pakistan Palau Panama Papua New Guinea Paraguay Peru Philippines Poland Portugal Puerto Rico Qatar Reunion Romania Russian Federation Rwanda Saint Helena Saint Kitts Saint Lucia Saint Pierre and Miquelon Saint Vincent and the Grenadines Samoa San Marino Saudi Arabia Senegal Serbia, Republic Of Seychelles Sierra Leone Singapore Slovakia Slovenia Solomon Islands Somalia South Africa South Korea Spain Sri Lanka Sudan Suriname Svalbard Swaziland Sweden Switzerland Syria Taiwan Tajikistan Tanzania Thailand Togo Tonga Trinidad and Tobago Tunisia Turkey Turkmenistan Turks and Caicos Islands Tuvalu Uganda Ukraine United Arab Emirates Uruguay Uzbekistan Vanuatu Vatican City State Venezuela Vietnam Virgin Islands (U.S.) Wallis and Futuna Western Sahara Yemen Zambia Zimbabwe We accept credit card payment transactions via the online checkout system! The checkout process is designed so that it communicates with the merchant to confirm that payment has been made and cleared. Other methods of payment are outlined through the online checkout process. Winning bidders must contact us within 3 days after auction close if special payment arrangements are needed. Your payment is expected within 5 days after the auction close. Unpaid auctions will be forfeited after 5 days of the auction close and the Item(s) will be relisted for sale. Items will be shipped within 24 hours (1 Business Day) upon receipt of payment from the winning bidder. (Certain orders may take longer for processing due to comprehensive final service inspections) A Shipment Tracking number(s) will be provided to inform Buyers of their expected ETA (Estimated Time of Arrival). Tracking number(s) will be provided the same day as order shipment. Thank you ALL MAJOR CREDIT CARDS & PayPal ACCEPTED Manage all your eBay listings with Kyozou eBay Listing Software
