Dc 3-18v Bistable Switch Single Key Circuit Module Timing Off For Industrial

US $1200

shenzhen, China
Oct 29th

Open on mobile:
QR code

New Arrivals Modules Home Gadgets Fishing Outdoor Product Picture Gallery Power Module Wireless Modules Sensor DIY LED Board Development Board Function Modules Digital Voltmeter Description DC 3-18V Bistable Switch Single Key Circuit Module Timing Off For Industrial Product Introduction: 1.Ordinary Function:falling adge trigger.Output port Vo initial state is open circuit,V1 port trigger once,Vo port becomes low level;trigger one more time,Vo output port becomes open circuit;then cycle 2.Setting Timing Auto Off Function:when Vo port output low level,can auto stop output after sometime (during the period of timing,can externally add trigger signal to stop output).Timing time can be set within the range of 1-15s (step distance is 1s) 3.Input port includeds switch contact shockproof circuit 4.Output port has protect diode and anti-interference circuit,can directly connect with inductive load 5.Power Voltage:DC 3V-18V 6.Static Current:1uA-2uA(power off);2mA (operating state) 7.Output:can directly drive within 1500mA resistive load for a long time (can withstand 2500mA in a short time) 8.Appliations:instrument device power control 9.Size:14*11mm (not include pin),pin space is 2.54mm Setting Method: 1,2,3,4 are used to set auto timing power off function;when all open circuit,module has ordinary function,trigger signal (operations),will not auto close output No.1 bonding pad short circuit,after output low level signal 1s,auto close output No.2 bonding pad short circuit,after output low level signal 2s,auto close output No 3 bonding pad short circuit,after output low level signal 4s,auto close output No.4 bonding pas short circuit,after output low level signal 8s,auto close output Above time can be accumulated,longest time is 15s Pin Definition: 1.VCC:power 2.Vo:output port 3.TG:trigger signal input port 4.GND:power ground Shippment Payment Return Policy Feedback About us We will arrange shipping for you within 24 Hours after payment cleared except the holidays. We only ship to the confirmed address provided by PayPal. Before you pay, please make sure your address in PayPal matches the address you would like us to ship to. If not, please let us know before we sent you the package, or we will not be responsible for any loss. hope you could understand. -We ship items to Worldwide. Thank you! -we will ship out the order in 1-2 business days after payment cleared .Since it is international shipping ,delivery time is about 15--28 business days to arrive to most countries. We accept Paypal ONLY. It is easy and safe for you to pay by credit cards, debit cards, bank transfers and PayPal account balances. * We believe our items are so outstanding. We are convinced you will be happy with your Purchase. * If you do not satisfy with our items. Please simply return to us within 30 Days in original condition. Just pay for the returned postage. Then we can issue full refund to you after the returned item arrived at our warehouse. * Please include your eBay ID and item number with any email requests. * When you satisfied with our product and services please leave us positive feedback. * If you have got the package, please confirm "Delivery on time" For us. * If a problem occurs, contact us immediately with any email request. * Just contact us using the " Ask the seller a question" link on eBay. We mainly sell Modules, IC Acccesories, Home Gadgets, and outdoor products. Almost all products you need, You can get a best price once you send us the ebay message. For bulk order or wholesale, we promise to offer you a very competitive price! We welcome do more pleasant business with you. SKYPE: ada-yu2013 inkfrog terapeak inkFrog Analytics On Oct-28-16 at 10:42:09 PDT, seller added the following information:
