DDS Function Signal Generator Module Sine Square Sawtooth Triangle Wave Kit NEW, US $1700 – Picture 0
DDS Function Signal Generator Module Sine Square Sawtooth Triangle Wave Kit NEW, US $1700 – Picture 0

Dds Function Signal Generator Module Sine Square Sawtooth Triangle Wave Kit New

US $1700

  • HK, Hong Kong
  • Jun 9th
Open on mobile:
QR code
Description Features: Function (waveform) signal generator. Can produce some specific periodic time function waveform (sine, square, triangle, sawtooth, and pulse wave, etc.) signal, the frequency range from a few Hz to tens of MHz micro-function signal generator circuit experiments and equipment detection of a very wide range of applications. Specification: • 100% Brand new • Operating voltage: DC7V-9V • Size: 100*80mm (Length*width) • Template thickness: 2mm • DDS frequency range: 1HZ-65534Hz. • High-speed frequency (HS) Square wave: 1MHz/2MHz/4MHz/8MHz • DDS signal amplitude of the offset amount can be adjusted separately by two potentiometers • DDS signals: sine wave, square wave, sawtooth, reverse sawtooth, triangle wave, ECG wave and noise wave • 1602 LCD screen • Intuitive 5 keyboard. • Section into the value: 1,10,100,1000,10000 Hz • The power automatically restores the last used configuration • Offset: 0.5pp-5Vpp • Amplitude amount: 0.5Vpp-14Vpp • Output Impedance: 20-200 ohms Buttons main functions: The UP output waveform select The DOWN output waveform select LEFT output frequency - RIGHT output frequency + STOP / RUN the output stop / start Package include: 1 x DDS Function Signal Generator Module   Detail Image Similar Items Payment 1.We accept PayPal only. 2.All major credit cards are accepted through secure payment processor PayPal. 3.Payment must be received within 7 business days of auction closing. 4.We ship to your eBay or Paypal address. Please make sure your eBay and Paypal address is correct before you pay. Shipping 1.We ship to your eBay or Paypal address. Please make sure your eBay and Paypal address is correct before you pay. 2.Items will be shipped within 1-3 business day when we received payment. 3.Delivery time depends on destination and other factors; 4.International buyers please note:   a.Import duties, taxes and charges are not included in the item price or shipping charges. These charges are buyer’s responsibility. We will try our best to reduce the risk of the custom duties.   b.Please check with your country's customs office to determine what these additional costs will be prior to buying.   On Oct-08-15 at 02:51:38 PDT, seller added the following information:
