Delta 100w 0.1kw A2 Servo System (drive + Motor) Asd-a2-0121-m + Ecma-c10401rs

US $760.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Delta 100W 0.1KW A2 Series Servo System (Drive + Motor) ASD-A2-0121-M + ECMA-C10401RS New Introuction Delta's new ASDA-A2 series is the ultimate servo system providing a total solution for a wide range of machine tools and industrial applications. Features *High Precision Control *Superlative Vibration Suppression *Flexible Internal Position Mode (Pr Mode) *Unique Built-in Electronic Cam (E-CAM) *Full Closed-loop Control (Capable of reading second feedback signals) *Max. 14 digital inputs. *Using powerful “Pr mode” is able to perform complex motions. *Quick connector is available for easy installation and use. *Built-in DC 24V power supply is provided to simplify the wiring and save space. Servo Drive and Servo Motor Combinations Power Servo Drive Servo Motor 100W ASD-A2-0121-_ ECMA-C10401_S (S=8mm) 200W ASD-A2-0221-_ ECMA-C10602_S (S=14mm) 400W ASD-A2-0421-_ ECMA-C10604_S (S=14mm) ECMA-C10804_7 (7=14mm) ECMA-E11305_S (S=22mm) ECMA-G11303_S (S=22mm) 750W ASD-A2-0721-_ ECMA-C10807_S (S=19mm) ECMA-G11306_S (S=22mm) 1000W ASD-A2-1021-_ ECMA-C11010_S (S=22mm) ECMA-E11310_S (S=22mm) ECMA-G11309_S (S=22mm) 1500W ASD-A2-1521-_ ECMA-E11315_S (S=22mm) 2000W ASD-A2-2023-_ ECMA-C11020_S (S=22mm) ECMA-E11320_S (S=22mm) ECMA-E11820_S (S=35mm) 3000W ASD-A2-3023-_ ECMA-E11830_S (S=35mm) ECMA-F11830_S (S=35mm) 4500W ASD-A2-4523-_ ECMA-F21845_S (S=35mm) 5500W ASD-A2-5523-_ ECMA-F21855_3 (3=42mm) 7500W ASD-A2-7523-_ ECMA-F21875_3 (3=42mm) Specifications ASDA-A2 Series 220V 100W 200W 400W 750W 1 KW 1.5 KW 2KW 3 KW 4.5 KW 5.5KW 7.5KW 01 02 04 07 10 15 20 30 45 55 75 Power supply Phase / Voltage Three-phase / Single-phase 220VAC Three-phase 220VAC Permissible Voltage Range Three-phase / Single-phase 200 ~ 230VAC, -15% ~ 10% Three-phase 200 ~ 230VAC, -15% ~ 10% Continuous Output Current (Arms) 0.9 1.55 2.6 5.1 7.3 8.3 13.4 19.4 32.5 40 47.5 Cooling System Natural Air Circulation Fan Cooling Encoder Resolution / Feedback Resolution 20-bit (1280000 p/rev) Control of Main Circuit SVPWM (Space Vector Pulse Width Modulation) Control Tuning Modes Auto / Manual Dynamic Brake None Built-in External Max. Input Pulse Frequency Max. 500Kpps / 4Mpps (Line driver), Max. 200Kpps (Open collector) Speed Control Mode Analog Input Command Voltage Range 0 ~ ±10 VDC Input Resistance 10K? Time Constant 2.2?s Speed Control Range 1:5000 1:3000 Torque Control Mode Analog Input Command Voltage Range 0 ~ ±10 VDC Input Resistance 10K? Time Constant 2.2?s Communication Interface RS-232 / RS-485 / CANopen / USB Environment Altitude Altitude 1000m or lower above sea level Atmospheric pressure 86kPa to 106kPa Operating Temperature 0°Cto 55°C (If operating temperature is above 45 °C, forced cooling will be required) Storage Temperature -20°Cto 65°C Humidity 0 to 90% (non-condensing) IP Rating IP20 Power System TN System Approvals IEC/EN 61800-5-1, UL 508C, C-tick ECMA Series 220V F118 30 45 55 75 Rated output power (kW) 3.0 4.5 5.5 7.5 Rated torque (N-m) 19.10 28.65 35.01 47.74 Maximum torque (N-m) 57.29 71.62 87.53 119.36 Rated speed (r/min) 1500 Maximum speed (r/min) 3000 Rated current (A) 19.4 32.5 40.0 47.5 Maximum current (A) 58.2 81.3 100.0 118.8 Power rating (kW/s) 66.4 105.5 122.9 159.7 Rotor moment of inertia (Kg. m2) (without brake) 54.95 77.75 99.78 142.7 Mechanical time constant (ms) 1.28 0.92 0.96 0.63 Torque constant-KT (N-m/A) 0.98 0.88 0.88 1.01 Voltage constant-KE (mV/(r/min)) 35.0 32.0 31.0 35.5 Armature resistance (Ohm) 0.077 0.032 0.025 0.015 Armature inductance (mH) 1.27 0.89 0.60 0.40 Electrical time constant (ms) 16.5 27.8 24.0 26.7 Insulation class Class A (UL), Class B (CE) Insulation resistance >100M?, DC 500V Insulation strength 1500V AC, 60 seconds Weight (kg) (without brake) 18.5 23.5 30.5 37.0 Weight (kg) (with brake) 22.5 29 36 53 Max. radial shaft load (N) 1470 1470 1764 1764 Max. thrust shaft load (N) 490 490 588 588 Power rating (kW/s) (with brake) 63.9 101.8 119.4 156.6 Rotor moment of inertia (Kg. m2) (with brake) 57.06 80.65 102.7 145.55 Mechanical time constant (ms) (with brake) 1.33 0.96 0.99 0.64 Brake holding torque [Nt-m (min)] 25.0 25.0 25.0 25.0 Brake power consumption (at 20°C) [W] 20.4 20.4 20.4 20.4 Brake release time [ms (Max)] 10 10 10 10 Brake pull-in time [ms (Max)] 70 70 70 70 Vibration grade (?m) 15 Operating temperature 0°C to 40°C Storage temperature -10°C to 80°C Operating humidity 20% to 90% RH (non-condensing) Storage humidity 20% to 90% RH (non-condensing) Vibration capacity 2.5G IP Rating IP65 Applications Precise carving machine, precise lathe/milling machine, double column type machining center, TFT LCD cutting machine, robot arm, IC packaging machine, high-speed packaging machine, CNC processing equipment, injection processing equipment, label inserting machine, food packaging machine, printing We accept Paypal only. Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com TradeManager: fasttobuy skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM We only use the DHL, FEDEX, UPS and EMS to ship the orders. Fast To Buy Ltd decide to choose the suitable express service for the orders . Fast To Buy Ltd is not responsible on the custom tax for any order. Customer should pay for the custom fee in any case. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: If you want to return the item, please contact us in 14 days first and make sure the package is un-opened. The buyer has to pay for the go and back delivery cost and the custom fee of each country. Fast To Buy Ltd will make refund for the part in 24 hours after receiving it. This returns policy does not affect your statutory rights. Fast To Buy Ltd won't take any responsibilities if customers provide wrong shipping infomation such as address, code or phone number etc. Kindly note: Pls check and confirm the part NO. and your application before place order, we can accept return or refund within 14 days for the quality reason only, thank you.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Delta
MPN	ASD-A2-0121-M + ECMA-C10401RS
Model	ASD-A2-0121-M + ECMA-C10401RS
Country of Manufacture	China
