Leadshine Servo Set(drive+motor) Acs606 + 57bl180 Dc18-60v 36vdc 180w 4000rpm

US $401.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Leadshine Brushless Servo Set (Drive + Motor) ACS606 + 57BL180 New ACS606 Introductions: Leadshine's fully digital AC servo drive ACS606 is developed with 32-bit DSP based on advanced control algorithm. Since its input commands are PUL/DIR signals, the users can upgrade stepping drives to the ACS606 without changing control systems. The ACS606 can offer high precision, high speed and high reliability performance, and widely used in inkjet printers, engraving machines, and etc. A built-in controller can be used for testing and tuning. PC based and handheld configuration & tuning tools can meet different tuning environments or requirements. The ACS606 can drive both DC brushless and AC servo motors.But it is more suitable for the DC brushless servo motors. Compare to the ACS806, the ACS606 has less I/O, thus has smaller size and higher cost-effective. Features: *Advance DSP current control technology *Step & Dir, or CW/CCW control *Input voltage: 18 - 60 VDC *Continuous current: 6 A *Peak current: 18A *Capable of driving 10 - 360 W brushless servo motors *Electronic gear rate from 1/255 to 255 *Built-in motion profile for testing with trapezoidal velocity profile *Opto-isolated *Small size, surface-mount technology Specifications: Parameters Min Typical Max Unit Peak output current 0 - 15 A Continue output current 0 - 6 A Supply voltage +18 - +60 VDC Logic signal current 7 10 16 mA Pulse input frequency 0 - 200 kHz Isolation resistance 500 M? Current provided to encoder - - 100 mA Matching motors: Power Models 25W BLM57025 50W BLM57050 90W BLM57090 130W BLM57130 180W BLM57180; 57BL180 Applications: Suitable for large and medium automation machines and equipments, such as inkjet printers, engraving machines, electronic manufacturing equipments, special NC machines, pick and place devices, packing devices, and so on. Particularly adapt to the applications require high speed, high precision, and low motor noise. Other hot items of this Leadshine brushless servo drives for above applications: ACS306 Leadshine Brushless Servo Drive ACS Series ACS306 DC18-30V Cont. 6A Peak 15A 150W for 10-150W Servo Motor New ACS606 Leadshine Brushless Servo Drive ACS Series ACS606 DC18-60V Cont. 6A Peak 18A 200W for 25-200W Servo Motor New ACS806 Leadshine Brushless Servo Drive ACS Series ACS806 DC18-80V Cont. 6A Peak 18A 400W for 50-400W Servo Motor New 57BL180 Introductions: Built with high quality materials, Leadshine 57BL180 is a 180W brushless DC servo motor at industrial quality. The standard model is integrated with a 4,000 PPR (1000-line) incremental encoder. It can provide smooth movement with low noise and motor heating in your motion control system. When driven by Leadshine ACS series servo drives, it can output the high torque you need at continuous speed from 1 rpm to 3000 rpm. It is a flange mounted motor, and mounting is compatible with NEMA23 stepper motors. At the cost even lower than many stepper systems on the market, this solution is ideal to upgrade your system from steppers to servos, or from brushed DC servos to brushless servos. It can offer AC-servo-like performance, such as high speed, high precision, low motor noise and low heating performance, while at the cost of normal stepper systems. Features: *Brushless construction *Reliable industrial quality *57mm screw mounted, 36 VDC rated voltage, 180W rated power *4000 CPR (1000-line) increamental encoder with A, B signals *0.57 N-m (81 oz-in) rated torque / 1.71 N-m (243 oz-in) peak *3000 RPM rated speed / 4000 RPM peak *Standard cabling options for direct connection to the ACS series servo drives Specifications: Parameters BLM57025 BLM57050 BLM57090 BLM57130 BLM57180 57BL180 Rated Voltage (VDC) 24 24 36 36 36 36 Rated Power (W) 25 50 90 130 180 180 Rated Torque (N.M) 0.08 0.16 0.29 0.41 0.57 0.43 Peak Torque (N.M) 0.24 0.48 0.87 1.23 1.71 1.27 Rated Speed (RPM) 3000 3000 3000 3000 3000 4000 Rated Current (A) 1.6 3 3.45 5.3 6.7 7 Peak Current (A) 4.8 9 10.35 15.9 20 20.5 Torque Const. (N.M/A) 0.05 0.053 0.084 0.078 0.085 0.063 Back EMF Const. (V/RPM) 5.2 5.55 8.8 8.2 8.9 6.6 Resistance (ohm) 1.73 0.88 1.35 0.63 0.9 0.35 Inductance (mH) 3.36 2.2 4.1 2.17 2 1 Inertia (kgm2 x 10-4 ) 30 75 119 173 230 230 Motor Length L (mm) 70 80 100 120 140 140 Mass (Kg) 0.25 0.5 0.75 1 1.25 1.25 Matching motors: Models Matching Drives BLM57025 ACS306, ACS606 BLM57050 ACS306, ACS606 BLM57090 ACS306, ACS606 BLM57130 ACS306, ACS606 BLM57180 ACS606 57BL180 ACS606 We accept Paypal only. Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com TradeManager: fasttobuy skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM We only use the DHL, FEDEX, UPS and EMS to ship the orders. Fast To Buy Ltd decide to choose the suitable express service for the orders . Fast To Buy Ltd is not responsible on the custom tax for any order. Customer should pay for the custom fee in any case. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: If you want to return the item, please contact us in 14 days first and make sure the package is un-opened. The buyer has to pay for the go and back delivery cost and the custom fee of each country. Fast To Buy Ltd will make refund for the part in 24 hours after receiving it. This returns policy does not affect your statutory rights. Fast To Buy Ltd won't take any responsibilities if customers provide wrong shipping infomation such as address, code or phone number etc. Kindly note: Pls check and confirm the part NO. and your application before place order, we can accept return or refund within 14 days for the quality reason only, thank you.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Leadshine
MPN	ACS606 + 57BL180
Model	ACS606 + 57BL180
Country of Manufacture	China
