Deluxe Heathkit Vtvm Probe Kit -complete Kit For Im-11/13/18/28/5218/5228 Meters

US $148

Marietta, Georgia, United States
May 28th

Open on mobile:
QR code

This kit includes the hardware and wire needed to build a set of test probes for most Heathkit (IM-11,13,18,28,5218,5228) Vacuum Tube Volt Meters and many others that use a single 1/4" phone style meter connection. (For 3 Wire units like Heathkit V4/5/6/7 units you will need additional banana plugs and slightly different wire setup - see my other auctions for A Complete Kit for these units) Typical application involves using one probe for DC Measurement (with the resistor installed) and the other probe for AC/Ohms Measurement. This dual probe setup, serves as a substitute for the mostly missing or incomplete original test probe which used a switch at the tip of the probe to switch the Resistor in/out of the circuit. Included in this version of the kit (many of which are hard to source economically): 1 Pair of Test Probes - 1 Red/1 Black 1 1/4" Mono Phone Plug w/Metal Housing and Clear Heat Shrink Sleeve 1 1Meg Ohm 1 Watt Resistor 1 Alligator Clip & Heat Shrink Tubing 2 Laminated Self Adhesive Probe Labels and Clear Heat Shrink Tubing to cover the probe labels, resulting in a professional and durable setup (see photos) 2 36" lengths of RG174 Coaxial Wire (used for DC & AC/Ohms test Leads) (Very Flexible - makes a great test lead) 1 36" Length of 18 Gauge Silicone Test Lead Wire (Very Flexible - High Quality) for the Ground Lead And also includes an emailed copy of a .PDF document describing the steps for building the test leads according to my method - most of the photographs are included in this auction listing. The original instructions specify shielded cable for the leads, the original supplied wire was a coaxial microphone style wire, many people use either standard (unshielded) test probe wire for the leads or a shielded coaxial cable, I Supply 2x36" pieces of black RG174 for the 2 leads and 1x36" piece of Black silicone test probe wire for the ground I Use these probes on my Heathkit IM-13,IM-18 and IM-28 meters with excellent results, and these meters are indespensible for working on Vintage Radio Gear (And I prefer them to my more modern FET meters for this type of work) There are several versions of these kits including a basic kit, deluxe kit and this deluxe kit with wire, I will offer completed probe sets soon, please check my other auctions. Attached is a photo of a completed set of test probes using this kit. The kit will be placed in a padded mailer and shipped with tracking no extra charge for additional units. Thanks for looking! 73's KK4HXJ Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
