Designer Kit For Mini-circuits Adp/jps Power Divider

US $44.99

  • Potomac, Maryland, United States
  • Jan 29th
This Designer Kit is for Mini-Circuits Surface Mount ADP and JPS Series Power Splitter/Combiner with "hv" Connection. Size of the PCB 1"x1"x0.031", FR-4 material, double-sided with soild plated ground on the back. Kit include: Machined Housing and Cover, 1 ea ADPDIV PCB, 1 ea SMA 2-Hole Flange Jack Receptacle Connector, 3 ea 2-56X3/16 Hex Head Screw (for SMA Connector), 6 ea 2-56X3/16 Pan Head Screw (for mount PCB), 6 ea 2-56X3/16 Flat Head Screw (for Cover), 4 ea  This PCB will fit Mini-Circuits ADP and JPS Series Power Splitter/Combiner for following part number: ADP-2-1W, ADP-2-10, ADP-2-20, ADP-2-20-75, JPS-2-IN, JPS-2-1W, JPS-2-4, JPS-2-900.
