Despatch Snb2-24-s Semiconductor Tool Conditioning Oven

US $4,925.40

Phoenix, AZ, United States
Jan 30th

Open on mobile:
QR code

Despatch SNB2-24-S Semiconductor Tool Conditioning Oven, Class 100, Nitrogen Atmosphere for Drying and Clean Holding of Tooling Comes with what you see in the pictures. If you don't see it, you probably wont get it. Specifications are from Despatch and may vary slightly due to upgrades, options, or revisions this unit may or may not have. The oven is guaranteed to work. List Price is: $32,836.00 Approx. NEW from Despatch The Unit's Serial Number Tag Reads: Model Number: SNB2-24-S Serial Number: 168273-L Max. Operating Temperature: 75°C (167°F) Heater Type: Electric Heater Capacity: 6 kW Heater Amps.: 16.7 A Largest Motor Amps: 3.4 A Total Motor Amps: 3.4 A Total Amps: 21.0 A Control Voltage: 24V, Single Phase, 60 Hz Line Voltage: 208V, Three Phase, 60 Hz Use of Equipment: Drying and Clean Loading of Tooling Exh. Damper Blade Cut to: Full Closing Link to the Datasheet: Despatch Semiconductor Tool Conditioning Oven Datasheet Link to the Main Temperature Controller: Despatch MIC 1422 Temperature Controller Manual Link to the High-Limit Temperature Controller: Despatch MIC 1162 High-Limit Temperature Controller Manual Description: SNB2-24 Nitrogen Atmosphere Class 100 Oven configured to meet the following process requirements: Drying and clean holding of tooling Standard Features: Class 100 conditions Nitrogen atmosphere Temperatures to 95°C (this one is setup for 75°C) Tool Conditioning Oven Description from Brochure: The Despatch Tool Conditioning Oven keeps semiconductor parts and tooling clean, dry, and ready for immediate installation. It is specifically designed for atmosphere controlled storage of parts, tooling, and deposition targets. Controlled Atmosphere: HEPA filters deliver better than Class 100 conditions. A clean, dry, nitrogen atmosphere ensures that the parts are not exposed to water vapors. Horizontal airflow provides uniform temperatures ranging from ambient to 95°C (again this is setup for 75°C). Padded Roll-out Shelves - The shelves are specially designed for semiconductor parts and tooling. A sturdy, roll-out design facilitates loading and unloading of heavy parts. Teflon padding eliminates damage from scratching and abrasion. (Standard on 300mm units; optional on 200mm units.) - (The shelves don't look like they are padded). 200mm and 300mm Sizes - Ovens are available in sizes designed for either 200mm or 300mm tools. NOT SURE WHAT SIZE THIS IS FOR! Specifications: Solid-state temperature controller with digital set point and chamber temperature readout. Offers precise control of oven temperature. Operating range from 50°C to 75°C. Operating temperature 60°C. Work chamber 42" wide, 24" deep, 42" high: 24.5 cubic feet. All dimensions are approximate. External dimensions 62" wide, 32" deep (plus 5" for door and door handles, and 4" for the relief vent in back), 73" high. Inert atmosphere capability. 6 kW heater capacity. Type 304-2B non-magnetic stainless steel interior and ducting. Exterior Paint: Trillium White. Horizontal airflow. Unique chamber design and 3 inches of high-grade insulation to minimize heat loss, external thermal spots and air leakage. Recirculating motor: .75 HP Motor Totally enclosed fan cooled motor construction. 99.97% HEPA filtration of recirculating air with filter challenge test port. Seismic bolt down holes. Pressure relief system. Bi-parting doors (no center post). Door switch disables heater, nitrogen injection and recirculating fan. Lockable mainline fused disconnect switch mounted in front of control panel. Despatch will supply a hole in the rear of the electrical compartment for running conduit directly to the disconnect switch. Power utilities: 208 Volts, 3 Phase, 60 Hertz. Shelf supports provide for nine shelf positions on 4" centers. 24 VAC control circuits. Higher voltage power circuit components to be touch-proof or have Lexan covers. Lexan lift panel to cover all controls on oven front. Emergency off switch located on front panel. Lexan cover to have hole for EMO access. Airflow switch on recirculation system to prove airflow Solid-state relay for proportioning temperature control. Digital single set point main control with separate hi-limit control. Manual reset hi-limit control. Water-cooling coil mounted in return duct to allow for 50°C operation. Despatch will supply pipe stubs for inlet and outlet water. Despatch also provides manual water flow control and valving to coil. (I believe this option is installed) Air-to-air heat exchanger. Fan not included. (I do not believe either of these options are installed.) Oven capacity - 400 pounds. For More Pictures Please Click the Following: Picture 2 - Back View Picture 3 - Front View, Doors Open Picture 4 - Nitrogen Controller Picture 5 - Despatch 1422 Temperature Controller Picture 6 - Despatch 1162 High Limit Temperature Controller Picture 7 - Nitrogen, Fan, & Heater Controls Picture 8 - Emergency Off Switch Picture 9 - Disconnect Switch Picture 10 - Exhaust Port Picture 11 - Piping on the Back Picture 12 - Line Connection Picture 13 - PCW Return Picture 14 - PCW Supply Picture 15 - PCW Supply Control Picture 16 - Nitrogen Supply Connection Picture 17 - Main Disconnect Tag Picture 18 - Design Specifications Tag #1 Picture 19 - Design Specifications Tag #2 $250.00 minimum for packaging, handling, and order processing. Shipping to be determined by destination. If you have any questions please email us at: ebay@mhzelectronics.com or call Michael at 1-866-MHZ-ELEC (1-866-649-3532) Toll Free. Also, please click here to view or other auctions! 09/09/06 Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Oct-31-13 at 21:12:41 PDT, seller added the following information: Click Here. Double your traffic. Get Vendio Gallery - Now FREE!
