Development Board Pic32 Pic32mx460f512l Usb Otg Tqfp100 No Pic Programmer Needed

US $230

Prague, Czech Republic
Jan 29th

Open on mobile:
QR code

end_display_feedback_code_window 100% Satisfaction guaranteed! This is a PIC32MX460F512L board! High-Performance, General Purpose and USB, 32-bit Flash Microcontrollers START STRAIGHT OUT OF THE BOX! No PIC programmer is required. The board has Microchip bootloader installed on it! SnadPIC... high quality at a great price!!! ========================================== You may need more MCU? Click TO CHOOSE A OR USB OTG MICROCONTROLLER : PIC32MX795F512L PIC32MX460F512L dsPIC33EP512MU810 PIC24EP512GU810 PIC24EP256GU810 and check out SnadPIC here! ========================== Overview The SnadPIC is a microcontroller board based on the Microchip PIC32, PIC24 and dsPIC families. It is designed to be easy to use and suitable for use by anyone from beginners to advanced users for experimenting with electronics and embedded control systems. It contains everything needed to start developing embedded applications. It is designed to provide a low cost small control solution. It is intended to introduce and demonstrate the capabilities and features of PIC32, PIC24 and dsPIC with on- chip USB OTG. The board also comes with all the basic components needed for the Microchip PIC32, PIC24 and dsPIC families, so you can use it straight out of the box. Except for a single connection to a computer, no additional hardware or configuration is necessary. A USB connection to a host computer supplies communications and power to the board. For independent host-side USB operation, the starter kit may be disconnected from the PC and powered through DC Power Jack for independent functionality. The starter kit provides 83 I/O pins that support a number of peripheral functions, such as UART, SPI and I2C™ ports and pulse width modulated outputs. Use of these advanced peripherals requires an add on board to provide the additional hardware required. Through the USB interface, it can also be programmed without the need of a programmer, as there is a built in Microchip boot loader. The starter kit can be powered via USB, an external DC power adapter, or batteries. Features • PIC32, PIC24 and dsPIC33 with on -chip USB OTG • Microchip bootloader Firmware • USB serial interface easily can be used as USB host and USB device • On-board Micro USB Connector • On-board Micro SD Card holder • On-board External Power Connector • On-board Power Supply Switch (ON OFF ON) • On-board 5V regulator • On-board 3.3V regulator • On-board Shield Power Connector • On-board RESET (MCLR) Switch • On-board General purpose Switch • On-board LED Power Supply indicator • On-board 8 User LEDs, and 1x8 male/female pin header that provides connections to these LEDs • Most of the processor pins available, and the breakout pins can be soldered with standard 0.1?male/female header to easily plug it into a mother board • 4 holes to fix the board into a mother board • On-board 8Mhz Crystal and two capacitors • On-board 32.768Khz Crystal and two capacitors for RTCC/Timer1 • On-board 1x6 footprint for ICSP connection that provides Microchip Debug Tool Connector • Board Size Inches (mm) : 3.94 (100.25) x 2.39 (60.95) __users_manual_snadpic100_rev1.02_.pdf Download File Do you need a demo application? Please contact us Here are more pictures of the starter kit: Here is what you get : ========================== If you don't know where to start, it is easy by visiting Microchip website.. Here is the link to all what you need : Once you download the Microchip Libraries for Applications you can select the projects that you need for your application. In addition to the source code, this software package includes: schematics, drivers, demos, documentation, and utilities. ========================== The device is new never been programmed before or tested. It was taken from its original package and soldered - with care - on the board : home, hand soldering skills. IT LOOKS LIKE IT WAS SOLDERED IN FACTORY! Every board is tested with SD Card, LEDs, and tested as a USB device and USB Host NO NEED TO ANOTHER PROGRAMMER TO START APPLICATIONS BUT IF YOU DON'T WANT TO USE THE BOOTLOADER SO: Warning for PICKIT3 Users Do not use the "programmer-to-go" button when there is no image on the programmer Doing so will put a PIC32 microcontroller into an irrecoverable state. See this Microchip Forum thread for details. -- --------------------- - Payment We kindly request to use PayPal Shipping Shipping is with a tracking number. We only ship to Paypal address. Please make sure to provide us with updated,correct, precise, and detailed shipping Address. We will not take any responsibility for any damage or functional problem which may be caused by the transportation, but We will pack Your item very carefully.All packages are packed professionally. Items will be shipped within 1 to 2 business days (even within hours) upon payment received or cleared. Contact seller BEFORE paying if you have any time constraints or need expedited service. Terms of Sale 100% Satisfaction guaranteed.If not we will give you full refund. No hassle No worries. Your satisfaction is very important to us. We accept returns for an exchange, or refund within 14 days of the items delivery. Items must be in their original condition, not worn, or altered. In their original package and we refund your money after we get the package! Shipping cost is NOT refundable and you should be responsible for the return shipping. Any refund, we will send you notice through ebay to cancel the transaction and refund to you at once after you accepted the cancellation. If we feel that the return policy is being abused we reserve the right to refuse any exchange. Feedback Once you have received your item, please leave feedback for us as this will inform us that you have received your items. We really need your positive feedback and 5 Star ratings after you receive your order, we will give you a positive feedback. Your satisfaction is most important for us. If you have a problem or question regarding your transaction, please contact us before leaving any type of feedback. And give us the opportunity to reasonably rectify in a reasonable amount of time, whatever your concern may be. Negative feedback does not solve anything. We are always willing to work things out. So feel free to contact us. We are new seller in Ebay , we really need positive feedback... On Oct-04-14 at 10:15:10 PDT, seller added the following information: Every buyer gets a MyStoreRewards invitation for cash back
