Digital ultrasonic flow meter TDS-100F-S2+M2 DN15-700mm wall-mount flowmeter, US $657.00 – Picture 0

Digital ultrasonic flow meter TDS-100F-S2+M2 DN15-700mm wall-mount flowmeter, US $657.00 – Picture 1

Digital ultrasonic flow meter TDS-100F-S2+M2 DN15-700mm wall-mount flowmeter, US $657.00 – Picture 2

Digital ultrasonic flow meter TDS-100F-S2+M2 DN15-700mm wall-mount flowmeter, US $657.00 – Picture 3

Digital ultrasonic flow meter TDS-100F-S2+M2 DN15-700mm wall-mount flowmeter, US $657.00 – Picture 4

Digital ultrasonic flow meter TDS-100F-S2+M2 DN15-700mm wall-mount flowmeter, US $657.00 – Picture 5

Digital ultrasonic flow meter TDS-100F-S2+M2 DN15-700mm wall-mount flowmeter, US $657.00 – Picture 6

Digital ultrasonic flow meter TDS-100F-S2+M2 DN15-700mm wall-mount flowmeter, US $657.00 – Picture 7

Digital Ultrasonic Flow Meter Tds-100f-s2+m2 Dn15-700mm Wall-mount Flowmeter

US $657.00

Shenzhen, China
Jun 9th

Open on mobile:
QR code

Digital ultrasonic flow meter TDS-100F-S2+M2 DN15-700mm wall-mount flowmeter Description: Is stationary time difference ultrasonic flowmeter flow body could be water, sea water, or oil, uniform liquid slurry, conduct electricity or not, corrosive or no corrosive liquid can be measured. Widely used in industrial field of various liquid flow metering online, which host is divided into standard wall hanging type, plate type, hanging type explosion-proof, the use of different field in order to meet user needs. Product features Low fixed ultrasonic flowmeter with large planning integrated circuits CPLD, table process, accuracy is higher. Price, high reliability, high performance, good applicability, full display in Chinese. Day, month and year flow accumulation function, can record run 64 days before the operation, the first 64 months, the first five years of accumulated flow operation. On low, the power management function, can record, electricity and traffic on 64 times before, can be manually or automatically compensate to reduce flow losses. Low effectively overcome the wall of the ultrasonic signal attenuation and rough surface of the pipe to scattering of ultrasonic signal from surface reduce the energy consumption of ultrasonic signal. Low overcame a signal to a small amount of sediment, suspended particles and bubbles, the effect of improved flow measurement accuracy, especially suitable for pipe flow measurement. When using a dedicated open hole tool that sensor in the zone without water supply installation, unique belt roller disassembly, installation method, does not affect the normal production, at any time to complete the on-line replacement and maintenance. Linearity Better than ±1%. Accuracy ±1% of reading at rates >0.6 ft/s (0.2m/s). Assume a fully developed flow profile. Repeatability ±0.2%. Velocity ±0.03 ~ ±105 ft/s (±0.01 ~ ±30 m/s), bi-directional Measurement Period 0.5s Display LCD with backlight. 2x20 letters. Keypad 4x4-key membrane keypad with tactile feedback Units English (U.S.) or metric. Outputs Analogue output: 4-20mA or 0-20mA current output. Impedance 0~1kW. Accuracy 0.1%. . Isolated OCT output: for frequency output (0~9,999Hz), alarm driver, or totaliser pulse output, ON/OFF control, etc. Relay output 1A@125VAC or 2A@30VDC. For ON/OFF control, alarm driver, totaliser output, etc. Internal Alarm (Buzzer): user programmable. External Alarm Driver: alarm signal can be transmitted to Relay or OCT output terminals to drive an external alarm. RS-232 serial port. Input Five channel 4-20mA current inputs for signals such as temperature, pressure, liquid level, and etc.. Accuracy 0.1%. Two of the five input channels are wired to terminal blocks. The remaining three channels are optional. Enclosure Die-cast aluminum enclosure. Protection Class: IP65 (NEMA 4X). Size: 9.88x7.56x3.15 (251x192x80mm3) for standard version Clamp-on S2-type: for pipe size (DN15~DN100mm) M2-type: for pipe size (DN50~DN700mm) L2-type: for pipe size (DN300~DN6,000mm) Liquid Types Virtually all commonly used clean liquids. Liquids with small quantity of tiny particles may also be applicable. Particle size should be less than 75um, particle concentration less than 10,000ppm. Liquids should contain no or very minor air bubbles. Examples are chilled/hot water, sea water, waste water, chemical liquids, oil, crude oil, alcohol, beer, etc. Liquid Temp (0C - 160C) for clamp-on transducer. Higher temperatures can be accommodated. Consult the manufacturer for assistance. (0C - 160C) for wetted transducer. Pipe Size 1 ~ 240 (DN15mm ~ DN6,000mm). Pipe Material All metals, most plastics, fiber glass, etc. Allow pipe liner. Cable Shielded transducer cable. Standard length 15 (5m). Can be extended to 1640 (500m). Contact the manufacturer for longer cable requirement. Power AC: 240V DC: 8VDC~36VDC Power consumption: < 2W Weight Standard main unit: 6.6lb (3kg) Transducer Standard S2 type Standard M2 type Standard L2 type Suitable pipe diameter DN15-DN100 DN50-DN700 DN300-DN6000 Fluid temperature 0°c-160°c 0°c-160°c 0°c-160°c Outer size 45x30x30mm 60x45x45 80x70x55 Quality 75g 250g 528g Standard Accessories: TDS-100 ultrasonic flow meter 1 set Clamp Fixture 1 set Standard S2 transducer 1 pair Standard M2 transducer 1 pair 2 x 2.5M Connection Cable Edited by ZACK PAYMENT INFORMATION: 1.We can accept Credit Cards,Paypal,T/T,Escrow and so on. 2.The buyer is responsible for any tax and/or duty charged by their country. INTERNATIONAL SHIPPING: The package will be shipped by DHL, FEDEX or EMS. After we shipped the parcel,we'll fill in the tracking number and inform you by e-mail.Please write the correct address and telephone number when you make orders,so the courier can contact you when they deliver the parcel to you. thanks WARRANTY INFORMATION: 1.All the products have been checked and packed in good condition before dispatch. 2.All the products with one year warranty. 3.If you find any quality problems,please send it back within 3 days,and we'll send you a new one or refund you the payment after we get the returned one. 4.Buyers have to pay for the return cost and we will pay the cost for resend 5.All products returned should be in new conditions. CONTACT US: Office Tel: 008675527541660 Cellphone: 008615967476828 1.A good feedback is very important for our store,if you feel satisfied with our products,please give us positive feedbacks. 2.Please contact us before leaving any negative or neutral feedback,We will work with you to solve any problems.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Graigar
Country/Region of Manufacture	China
Model	TDS-100F
MPN	Does Not Apply
