Dual Motor Driver Module Board H-bridge Dc Mosfet Irf3205 3-36v 15a Peak30a

US $16.71

ShenZhen, China
Sep 1st

Open on mobile:
QR code

sunshinylight04 Product Description Description: Features: The driver focus on current and efficiency, effectively motor power and battery life. Can withstand high current overload, the maximum current up to 30A. This drive also has a brake function can be quickly stopped the motor, brake quickly, braking obvious, easy to implement this feature The drive uses the full two half-bridge driver chip + low resistance N-channel MOSFET components. Complete two half-bridge driver chip reliable drive mode, the MOSFET switching losses to a minimum. Improve power utilization. MOSFET driver chip comes with hardware brake function and power feedback. This drive is superior integrated low power chip solution and the other half-bridge power margin in the coordinated combination of programs and complex issues and complementary drive problems N-channel MOSFET IRF3205 MOSFET, use two dedicated half-bridge driver chip on the top tube using the bootstrap capacitor, so that the tube has enough drive voltage of the MOSFET channel can be opened quickly, improve motor acceleration curvature, but also quickly for the motor brake. This allows the trolley can quickly start can quickly kill the car. The driver can operate at 0% -99% of the duty cycle of the PWM modulation, the motor driving voltage can be obtained sufficiently. Motor forward: DIR = 1 PWM = PWM Motor reversal: DIR = 0 PWM = PWM Parking brake: DIR = X PWM = 0 (X is an arbitrary state) Motor and power connections POWER connected to the positive power supply, GND power supply is negative. Two motors were connected MOTOR1, MOTOR2 Specification: Rated voltage: DC 3V-36V Rated Current: 15A Peak current: 30A Product size: approx. 100*70*21mm/3.93*2.75*0.82'' Net weight: approx. 53g Please note: It is manual measurement, there may be 1-3mm error. And item color displayed in photos may be showing slightly different on your computer monitor since monitors are not calibrated same.hope understanding. Included: 1 x Dual Motor Driver Module Board 15A pictures

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Rated voltage	DC 3V-36V
Net weight	approx. 53g
Rated Current	15A
Brand	Unbranded
Peak current	30A
MPN	Does Not Apply
Product size	approx. 1007021mm/3.932.750.82''
UPC	Does Not Apply
EAN	Does Not Apply
