Dual Vnh2sp30 Stepper Motor Driver Module 30a Monster Moto Shield Replace L298n

US $140

Shanghai, China
Jun 9th

Open on mobile:
QR code

dual vnh2sp30 stepper motor driver module 30a monster moto shield replace l298n Specification: this is essentially a ramped up version of our Ardumoto motor driver shield. For this monster shield we've replaced the L298 H-bridge with a pair of VNH2SP30 full-bridge motor drivers. We've also beefed up the support circuitry so this board is capable of driving a pair of high-current motors! The VIN and motor out are pitched for our 5mm screw terminals (not included), making it easy to connect larger gauge wires. Note: When using this board in extreme high-demand applications it may be necessary to improve thermal performance with a heat-sink or fan and to solder the wires directly to the board instead of using a screw terminal (in addition to the myriad other complications present in a high-current system) However, when using the board at currents up to 6A the chips will barely become noticeably warm. Features: Voltage max: 16V. Maximum current rating: 30 A. Practical Continuous Current: 14 A. Current sensing available to Arduino analog pin. MOSFET on-resistance: 19 m? (per leg). Maximum PWM frequency: 20 kHz. Thermal Shutdown. Undervoltage and Overvoltage shutdown. Documents: Schematic Eagle Files Datasheet (VNH2SP30) Example Code fugngzm sijpidk qyklede MPI Buyer should pay within 7 days after purchase. We only accept payment via PayPal. Our team focuses on providing high quality products with reasonable price and tries its best to keep transactions as simple as possible. Please be confident of and enjoy your shopping here! Please feel free to contact us via eBay message system or email.
