DUNCAN VARIABLE RESISTOR # 1511-1042 NSN: 5905-01-019-1203 # RR1300B2B7U202, US $57 – Picture 0
DUNCAN VARIABLE RESISTOR # 1511-1042 NSN: 5905-01-019-1203 # RR1300B2B7U202, US $57 – Picture 0

Duncan Variable Resistor # 1511-1042 Nsn: 5905-01-019-1203 # Rr1300b2b7u202

US $57

  • Huntington Station, New York, United States
  • Jun 11th
Open on mobile:
QR code
Part details include a required section quantity of 1, and a body style of cylindrical servo-mounted. The reliability indicator has not been established, the pilot diameter is between 1.3120 inches minimum and 1.3125 inches maximum, and the pilot length is 0.0620 inches nominal. The Duncan variable resistor, part number 1511-1042, is a reliable and high-quality component with national stock number 5905-01-019-1203 and part number RR1300B2B7U202. This cylindrical servo-mounted resistor is brand new surplus from 1986 with date codes (8633). We only ship within the continental USA and accept PayPal payments exclusively. Other details include a maximum running torque of 0.75 inch-ounces, a shaft end play of 0.005 inches, a shaft runout of 0.001 inches, and lateral runout of 0.001 inches. The pilot diameter runout is 0.001 inches, and the shaft radial play is 0.002 inches. The mechanical backlash in degree angular rotation is 0.1. This resistor has a function conformity tolerance per section of M0.25/P0.25 single section, and the ambient temperature in degree Celsius per The terminal location is radially positioned over less than half the circumference, and the mounting method is via clamp ring. The electrical resistance per section is 2.0 kilohms per single section, and the rotary actuator travel in angular degree is 360.0 nominal. The overall diameter is 1.828 inches maximum, and the mounting lip diameter is 1.4370 inches nominal. The mounting lip depth is 0.0930 inches nominal, and the shaft style is round. The actuator type is a single shaft with an effective electrical rotation in degree angular rotation of 350.0 nominal. The overall length is 1.593 inches maximum, and the undercut diameter is 1.31300 inches maximum. The undercut width is 0.0730 inches minimum, the body diameter is 1.468 inches maximum, and the shaft diameter ranges from 0.2494 inches minimum to 0.250 inches maximum. The shaft length is 0.500 inches nominal, and the body length is 1.062 inches maximum. If you intend to export this item, it is your responsibility to ensure compliance with all export regulations, both foreign and domestic.
