Dvb Dsng Dvb-s/s2 Mpeg 2/4 Sspa 25w Ku Band Amplifier L-band To 14.0-14.5ghz

US $2,000.00

  • Sofia, Sofia, Bulgaria
  • Jan 29th
Open on mobile:
QR code
 SPECIFICATIONS PERFORMANCE Model DBE-140145-25-N-48 DBE-140145-16-N-48 Transmit Frequency 14.0-14.5 GHz Input Frequency 950-1450 MHz LO Frequency 13050 MHz Frequency Sense Non-Inverting Maximum Input Level w/o Damage + 10 dBm Max Reference Signal Frequency: External 10 MHz Input Power: -5 to +5 dBm at Input Port Phase Noise: -125 dBc/Hz max @ 100 Hz -135 dBc/Hz max @ 1 kHz -140 dBc/Hz max @ 10 kHz P1dB Output Power > 44 dBm > 42 dBm Rated Output Power 44 dBm 42 dBm Small Signal Gain 70 dB nominal Intermodulation with two equal carriers (5 MHz apart) at 3 dB total power backoff from Rated Power -25 dBc Spectral Regrowth at 2dB below Rated Power at 1.5x symbol rate offset for OQPSK -30 dBc Phase Noise Meets IESS-308 Output Spurious -60 dBc Receive Band Noise Power -150 dBW/4kHz maximum IF Input VSWR 2:1 max RF Output VSWR 1.3:1 max PRIME Upconverter Power 24 VDC (15-30 VDC) on IFL 30W max, 22W typical HPA Power 48 VDC (min. 36 VDC, max. 60 VDC) <4.0 Amps @ Rated Power <3 Amps @ 3 dB backoff from Rated Power INTERFACES IF Port Connector Type N Female IF Input Impedance 50 Ohm RF Port Connector WR-75 DC Connector 3-Pin Male - ITT Cannon CB2-16-10PS (mating CB6E16-10SS) Monitor and Control Connector 26-Pin Female - ITT Cannon KPT02E16- 26S (mating KPT06E16-26P) Discrete Monitor Signals Prime Power, TX Active, HPA Off, Over Temp, DC-DC Good Discrete Control Signals TX Enable LED Indicators Prime Power, TX Enable, HPA Off, Over Temp ENVIRONMENTAL SPECIFICATIONS Operating Temperature -40oC to +50oC ambient air temperature Water Ingress IP-24 MECHANICAL SPECIFICATIONS Size 7.0” W x 5.2” H x 9.0” L (165 mm W x 120 mm H x 203 mm L) Weight 9.2 lbs (4.2 Kg) AMPLIFIER ONLY, WITHOUT ANOTHER THINGS FROM PHOTOS TESTED, WORKING PROPERTY CAN BE UPGRADE TO EXTENDED MODE 13.75-14.5GHZ WITH ORIGINAL PARTS +400$
